SANYO DENKI 65BA030VDTB8伺服放大器 PDF资料
1.产 品 资 料 介 绍：
Sanyo Denki 65BA030VDTB8 伺服放大器特点
产品系列：SANMOTION 系列
产品类型：交流伺服放大器（AC Servo Amplifier）
主要功能：驱动与控制 Sanyo Denki 伺服电机，实现高精度位置、速度与扭矩控制。
一、技术参数
额定输入电压：三相 AC 200～230 V
额定输出电流：约 3 A
功率范围：约 0.4～0.5 kW
控制方式：全数字矢量控制
驱动信号方式：脉冲 + 模拟信号输入
编码器接口：支持增量式或绝对式反馈（取决于配置）
冷却方式：自然冷却或外部风冷
安装方式：竖直面板安装
防护等级：IP20
绝缘等级：F 级
二、性能特点
高精度控制 —— 内部采用高速 DSP 芯片，反馈回路响应快，控制精度高。
动态性能优越 —— 适合频繁启停或加减速运行的应用环境。
多模式兼容 —— 可在位置、速度、转矩三种模式间灵活切换。
内置保护功能 —— 具备过流、过压、欠压、过热、短路、编码器异常等多种保护机制。
参数自动调谐 —— 驱动器可自动识别伺服电机特性，实现快速整定。
体积紧凑 —— 节省控制柜空间，布线方便。
高可靠性设计 —— 采用优质功率器件及隔离控制结构，运行稳定。
SANYO DENKI 65BA030VDTB8伺服放大器 英文介绍
Sanyo Denki 65BA030VDTB8 servo amplifier features
Product series: SANMOTION series
Product type: AC Servo Amplifier
Main function: Drive and control Sanyo Denki servo motors to achieve high-precision position, speed, and torque control.
1、 Technical parameters
Rated input voltage: three-phase AC 200-230 V
Rated output current: approximately 3 A
Power range: approximately 0.4-0.5 kW
Control method: Full digital vector control
Drive signal mode: pulse+analog signal input
Encoder interface: Supports incremental or absolute feedback (depending on configuration)
Cooling method: natural cooling or external air cooling
Installation method: Vertical panel installation
Protection level: IP20
Insulation level: F level
2、 Performance characteristics
High precision control - using high-speed DSP chips internally, with fast feedback loop response and high control accuracy.
Superior dynamic performance - suitable for application environments with frequent start stop or acceleration/deceleration operations.
Multi mode compatibility - flexible switching between position, speed, and torque modes.
Built in protection function - equipped with multiple protection mechanisms such as overcurrent, overvoltage, undervoltage, overheating, short circuit, encoder abnormality, etc.
Parameter automatic tuning - The driver can automatically recognize the characteristics of the servo motor and achieve fast tuning.
Compact size - saves control cabinet space and facilitates wiring.
High reliability design - using high-quality power devices and isolation control structures for stable operation.
SANYO DENKI 65BA030VDTB8伺服放大器 产品展示
