SANYO DENKI 65BA030VDT10伺服放大器 PDF资料
1.产 品 资 料 介 绍：
Sanyo Denki 65BA030VDT10 伺服放大器特点
产品系列：SANMOTION 系列
产品类型：交流伺服放大器（AC Servo Amplifier）
应用领域：与 Sanyo Denki 伺服电机配套使用，用于高精度位置、速度及转矩控制系统。
一、基本参数
额定输入电压：三相 AC 200～230 V
额定输出电流：约 3 A
控制方式：全数字矢量控制
功率等级：约 0.4～0.5 kW 对应电机适配
频率：50/60 Hz
冷却方式：自然冷却或强制风冷（视安装环境）
安装方式：竖直面板安装
绝缘等级：F 级
防护等级：IP20
二、性能特点
高响应控制 —— 内部采用高速数字信号处理器（DSP），运算精度高，响应时间短。
位置精度高 —— 支持高分辨率反馈，适合精密定位场合。
兼容性强 —— 可与多种规格的 Sanyo Denki 电机搭配使用。
多控制模式 —— 位置、速度、转矩控制可单独或复合运行。
稳定可靠 —— 具备过压、过流、欠压、过热、短路、接地等多重保护功能。
自整定功能 —— 自动检测电机惯量参数，简化调试。
节能设计 —— IGBT高效驱动结构，损耗低，效率高。
三、典型应用
自动化生产设备
数控机床
包装机械
电子装配线
机械手与输送系统
精密测量与定位装置
SANYO DENKI 65BA030VDT10伺服放大器 英文介绍
Sanyo Denki 65BA030VDT10 servo amplifier features
Product series: SANMOTION series
Product type: AC Servo Amplifier
Application field: Used in conjunction with Sanyo Denki servo motors for high-precision position, speed, and torque control systems.
1、 Basic parameters
Rated input voltage: three-phase AC 200-230 V
Rated output current: approximately 3 A
Control method: Full digital vector control
Power level: approximately 0.4-0.5 kW corresponding to motor adaptation
Frequency: 50/60 Hz
Cooling method: natural cooling or forced air cooling (depending on the installation environment)
Installation method: Vertical panel installation
Insulation level: F level
Protection level: IP20
2、 Performance characteristics
High response control - using a high-speed digital signal processor (DSP) internally, with high computational accuracy and short response time.
High position accuracy - supports high-resolution feedback, suitable for precision positioning occasions.
Strong compatibility - can be used with Sanyo Denki motors of various specifications.
Multiple control modes - position, speed, and torque control can operate separately or in combination.
Stable and reliable - equipped with multiple protection functions such as overvoltage, overcurrent, undervoltage, overheating, short circuit, and grounding.
Self tuning function - automatically detect motor inertia parameters, simplify debugging.
Energy saving design - IGBT high-efficiency driving structure, low loss, high efficiency.
3、 Typical applications
Automated production equipment
CNC machine tool
packaging machinery
Electronic assembly line
Mechanical arm and conveying system
Precision measurement and positioning device
SANYO DENKI 65BA030VDT10伺服放大器 产品展示
