SANYO DENKI GC50-U050伺服控制器 PDF资料
1.产 品 资 料 介 绍：
一、型号定位与功能
GC50‑U050 属于 SANYO DENKI 的 GC50 系列伺服驱动模块，用于驱动伺服电机并实现位置、速度、转矩等闭环控制。
“U050”表示该型号在系列中的电流/功率等级。
二、主要规格
输入电压：200–230 V AC（50/60 Hz）
直流输入（部分版本支持）：约 270–311 V DC
输出额定电流：约 8.3 A
安装形式：面板安装或柜内安装，具备通风散热通道
工作环境：环境温度 0°C 至 55°C，无凝露条件下运行
三、产品特点
兼容性强
可与 SANYO DENKI 的伺服电机系统配合使用，适用多种自动化场合。多制式电源支持
支持交流输入，同时部分版本支持直流输入，提高安装灵活性。中功率输出等级
输出电流约 8.3 A，适合中功率伺服系统。结构紧凑、安装简易
模块化设计便于在控制柜中布局。维护便捷
配备指示灯和状态监测功能，有利于故障诊断。
四、使用与选型建议
电机匹配：选用控制器时，应确认所驱动伺服电机的额定电流不超过 8.3 A，以避免过载。
电源确认：确保供电电压稳定，符合 AC 或直流版本要求。
安装散热：安装时应留足散热空间，避免高温导致降额或故障。
布线规范：伺服电源线、编码器线、控制信号线应屏蔽、分离布线，减少干扰。
运行环境：确保环境温度、湿度在规格范围内，避免极端环境使用。
调试阶段：首次使用建议低速空载试运行，确认驱动器、电机及反馈系统状态正常后再负载运行。
SANYO DENKI GC50-U050伺服控制器 英文介绍
1、 Model positioning and functionality
GC50-U050 belongs to SANYO DENKI's GC50 series servo drive module, which is used to drive servo motors and achieve closed-loop control of position, speed, torque, etc.
U050 "represents the current/power level of the model in the series.
2、 Main specifications
Input voltage: 200-230 V AC (50/60 Hz)
DC input (supported in some versions): approximately 270-311 V DC
Rated output current: approximately 8.3 A
Installation form: panel installation or cabinet installation, with ventilation and heat dissipation channels
Working environment: Operating at an ambient temperature of 0 ° C to 55 ° C without condensation
3、 Product Features
Strong compatibility
Can be used in conjunction with SANYO DENKI's servo motor system, suitable for various automation scenarios.
Multi standard power supply support
Supports communication input, and some versions also support DC input to improve installation flexibility.
Medium power output level
The output current is about 8.3 A, suitable for medium power servo systems.
Compact structure and easy installation
Modular design facilitates layout in the control cabinet.
Easy maintenance
Equipped with indicator lights and status monitoring functions, it is beneficial for fault diagnosis.
4、 Usage and selection suggestions
Motor matching: When selecting a controller, it should be confirmed that the rated current of the driven servo motor does not exceed 8.3 A to avoid overload.
Power confirmation: Ensure that the power supply voltage is stable and meets the requirements of AC or DC versions.
Installation heat dissipation: Adequate heat dissipation space should be left during installation to avoid high temperatures causing derating or malfunctions.
Wiring specifications: Servo power lines, encoder lines, and control signal lines should be shielded and separated to reduce interference.
Operating environment: Ensure that the ambient temperature and humidity are within the specified range, and avoid extreme environmental use.
Debugging phase: It is recommended to conduct a low-speed no-load trial run for the first use, and confirm that the driver, motor, and feedback system are in normal condition before running under load.
SANYO DENKI GC50-U050伺服控制器 产品展示
