SANYO DENKI R2AA2250ALCPKL伺服电机 PDF资料
1.产 品 资 料 介 绍：
基本信息
品牌：SANYO DENKI（三洋电机）
型号：R2AA2250ALCPKL
系列：SANMOTION R 系列交流伺服电机
输出功率：约 0.55 kW（550 W）
机座尺寸：法兰约 220 mm 方形（大机座）
编码器类型：带绝对编码器（具体选项“ALCPKL”可能包含备选编码器类型）
防护结构：适用于工业环境，结构稳固、适合高负荷应用
特性与优势
高精度定位：作为 SANMOTION R 系列产品，其设计目标为高分辨率编码器与高响应控制系统。
大机座设计：机座尺寸较大（220 mm）意味着适合中/大型机械装置或高扭矩需求场合。
稳定可靠：结构设计用于承载较大机械惯量负载，适合复杂运动控制系统。
安装便利：结构适合工业环境安装，机械连接与布线都具有较好的可操作性。
使用建议
驱动器匹配：使用此电机时，所配的伺服驱动器／放大器必须在电压、电流、功率、编码器反馈等方面与电机匹配。
安装对中注意：由于机座大、负载可能大，安装时确保轴与联轴器同心、机座固定稳固，以避免因机械偏载造成寿命损耗。
散热与环境：大功率电机运行时热量较大，应保证良好通风、散热条件，环境温度、湿度应符合厂商推荐。
备件与替代：若该型号较少现货或停产，应考虑备件供应情况，或选择规格相近的替代型号。
启动／负载余量：若设备负载变化大或将来有升级需求，建议在选型时预留余量（功率、电流、扭矩）以适应未来变化。
SANYO DENKI R2AA2250ALCPKL伺服电机 英文介绍
Basic Information
Brand: SANYO DENKI (Sanyo Electric)
Model: R2AA2250ALCPKL
Series: SANMOTION R series AC servo motor
Output power: approximately 0.55 kW (550 W)
Machine base size: flange approximately 220mm square (large machine base)
Encoder type: with absolute encoder (specific option "ALCPKL" may include alternative encoder types)
Protective structure: suitable for industrial environments, structurally stable, and suitable for high load applications
Features and Benefits
High precision positioning: As a SANMOTION R series product, its design goal is high-resolution encoders and high response control systems.
Large machine base design: A larger machine base size (220mm) means it is suitable for medium/large mechanical devices or high torque demand applications.
Stable and reliable: The structural design is used to carry large mechanical inertia loads, suitable for complex motion control systems.
Easy installation: The structure is suitable for installation in industrial environments, and both mechanical connections and wiring have good operability.
Usage recommendations
Driver matching: When using this motor, the servo driver/amplifier equipped must match the motor in terms of voltage, current, power, encoder feedback, etc.
Attention to installation alignment: Due to the large size of the machine base and possible high load, ensure that the shaft and coupling are concentric and the machine base is firmly fixed during installation to avoid life loss caused by mechanical overload.
Heat dissipation and environment: High power motors generate a large amount of heat during operation, and good ventilation and heat dissipation conditions should be ensured. The ambient temperature and humidity should comply with the manufacturer's recommendations.
Spare parts and substitutes: If the model is in short supply or discontinued, consideration should be given to the supply of spare parts, or alternative models with similar specifications should be selected.
Startup/load margin: If the equipment load changes significantly or there is a need for future upgrades, it is recommended to reserve margin (power, current, torque) when selecting to adapt to future changes.
SANYO DENKI R2AA2250ALCPKL伺服电机 产品展示
