SANYO DENKI Q3AA13150HBZTA伺服电机 PDF资料
1.产 品 资 料 介 绍：
SANYO DENKI Q3AA13150HBZTA 伺服电机
基本参数：
品牌：SANYO DENKI（三洋电机）
型号：Q3AA13150HBZTA
系列：SANMOTION Q 系列
类型：三相交流伺服电机
额定功率：约 1.5 kW
额定转速：2000 rpm
额定电压：200V 三相
额定电流：约 7.8A（峰值 8.9A）
重量：约 12.3 kg
轴径：约 22 mm
产品特点：
高精度定位控制，响应速度快，适用于中高端自动化设备。
转矩输出稳定，具备较强的过载能力。
内置高分辨率编码器，确保运动控制的平滑性与精确度。
低振动、低噪音设计，运行平稳。
结构紧凑，适合空间受限的安装环境。
具有良好的散热性能，可连续高效运行。
使用注意事项：
电机的额定电压与驱动器输出电压必须匹配。
选配的伺服驱动器应能提供足够的峰值电流。
安装时应确保联轴器同心度良好，避免轴向或径向应力过大。
保持良好通风，避免长时间过载运行。
检查电机编码器信号类型与控制系统是否兼容。
定期清洁电机外壳，防止灰尘积聚影响散热。
应用领域：
数控机床
包装机械
搬运与装配设备
机器人关节驱动
精密定位与运动控制系统
SANYO DENKI Q3AA13150HBZTA伺服电机 英文介绍
SANYO DENKI Q3AA13150HBZTA servo motor
Basic Parameters:
Brand: SANYO DENKI (Sanyo Electric)
Model: Q3AA13150HBZTA
Series: SANMOTION Q Series
Type: Three phase AC servo motor
Rated power: approximately 1.5 kW
Rated speed: 2000 rpm
Rated voltage: 200V three-phase
Rated current: approximately 7.8A (peak 8.9A)
Weight: Approximately 12.3 kg
Shaft diameter: approximately 22 mm
Product Features:
High precision positioning control, fast response speed, suitable for mid to high end automation equipment.
Stable torque output and strong overload capacity.
Built in high-resolution encoder ensures smoothness and accuracy of motion control.
Low vibration, low noise design, smooth operation.
Compact structure, suitable for installation environments with limited space.
Has good heat dissipation performance and can operate continuously and efficiently.
Precautions for use:
The rated voltage of the motor must match the output voltage of the driver.
The optional servo drive should be able to provide sufficient peak current.
During installation, ensure good concentricity of the coupling to avoid excessive axial or radial stress.
Maintain good ventilation and avoid prolonged overload operation.
Check if the signal type of the motor encoder is compatible with the control system.
Regularly clean the motor casing to prevent dust accumulation from affecting heat dissipation.
Application fields:
CNC machine tool
packaging machinery
Handling and assembly equipment
Robot joint drive
Precision positioning and motion control system
SANYO DENKI Q3AA13150HBZTA伺服电机 产品展示
