Extreme Networks X870-96X-8C电源模块 PDF资料
1.产 品 资 料 介 绍：
Extreme Networks X870-96X-8C 电源模块
一、产品概述
Extreme Networks X870-96X-8C 电源模块是为 X870 系列高性能交换机设计的冗余电源单元，提供稳定的直流或交流供电，确保设备在高负载和长时间运行中依旧保持可靠性能。该模块支持热插拔设计，可在不影响系统运行的情况下进行更换或维护。
二、主要技术规格
适用设备：X870-96X-8C 高密度万兆/百兆以太网交换机
输入电压范围：100–240V AC 或 -48V DC（具体型号可选）
额定功率：770W / 1100W（不同版本支持）
频率范围：50 / 60 Hz
效率等级：高达 90% 以上
冷却方式：智能温控风扇散热
安装方式：模块化热插拔设计
指示灯状态：支持电源状态与告警指示
三、主要特点
高可靠性设计：采用冗余电源架构，支持双电源热备，提高系统稳定性。
热插拔支持：可在设备通电状态下更换，无需中断交换机运行。
高能效转换：优化电源转换效率，降低能耗与发热量。
智能散热系统：根据设备负载与温度自动调节风扇速度，延长模块寿命。
模块化安装：方便维护与扩展，支持快速部署和更换。
电源状态监测：通过前面板 LED 提供清晰的运行状态与告警指示。
Extreme Networks X870-96X-8C电源模块 英文介绍
Extreme Networks X870-96X-8C power module
1、 Product Overview
The Extreme Networks X870-96X-8C power module is a redundant power unit designed for the X870 series high-performance switches, providing stable DC or AC power supply to ensure reliable performance even under high loads and prolonged operation. This module supports hot swappable design and can be replaced or maintained without affecting system operation.
2、 Main technical specifications
Applicable equipment: X870-96X-8C high-density 10G/100Mbps Ethernet switch
Input voltage range: 100-240V AC or -48V DC (specific model optional)
Rated power: 770W/1100W (supported by different versions)
Frequency range: 50/60 Hz
Efficiency level: up to 90% or above
Cooling method: Intelligent temperature control fan for heat dissipation
Installation method: Modular hot swappable design
Indicator light status: Supports power status and alarm indication
3、 Main features
High reliability design: Adopting a redundant power architecture, supporting dual power hot standby, and improving system stability.
Hot swappable support: can be replaced while the device is powered on, without interrupting the operation of the switch.
High energy efficiency conversion: Optimize power conversion efficiency, reduce energy consumption and heat generation.
Intelligent cooling system: automatically adjusts fan speed according to device load and temperature, extending module life.
Modular installation: easy to maintain and expand, supports rapid deployment and replacement.
Power status monitoring: Clear operating status and alarm indications are provided through the front panel LED.
Extreme Networks X870-96X-8C电源模块 产品展示
