Extreme Networks X590-24X-1Q-2C端口交换机 PDF资料
1.产 品 资 料 介 绍：
Extreme Networks X590-24X-1Q-2C 交换机
一、产品简介
Extreme Networks X590-24X-1Q-2C 是一款高性能的 24 端口千兆/万兆以太网交换机，专为企业网络和数据中心设计，提供灵活的连接选项和强大的管理功能，满足现代网络对高密度接入和高速数据传输的需求。
二、主要规格
端口配置：
24 个 10/100/1000BASE-T RJ45 端口
1 个 10Gb/40Gb QSFP+ 上行端口
2 个 10Gb/25Gb/40Gb/50Gb/100Gb QSFP28 上行端口
1 个 10/100/1000BASE-T 管理端口
1 个串行控制台端口
交换容量：880 Gbps
转发速率：714 Mpps
内存配置：
2 GB DDR3 ECC 内存
4 GB eMMC 闪存
电源要求：
支持 770W AC 或 1100W DC 电源模块（模块化设计）
风扇模块：4 个可热插拔风扇模块
尺寸：44.1 cm (W) x 48.8 cm (D) x 4.35 cm (H)
重量：约 6.6 kg
三、关键特性
高密度端口配置：提供 24 个 10/100/1000BASE-T RJ45 端口，满足企业网络对接入层的需求。
高速上行链路：支持 1 个 10Gb/40Gb QSFP+ 上行端口和 2 个 10Gb/25Gb/40Gb/50Gb/100Gb QSFP28 上行端口，适应不同的网络拓扑和带宽需求。
高性能交换能力：具备 880 Gbps 的交换容量和 714 Mpps 的转发速率，确保高速数据传输。
灵活的电源和风扇配置：支持模块化电源和风扇模块，提供冗余和高可用性。
智能管理功能：运行 ExtremeXOS 操作系统，支持 Layer 2/Layer 3 切换、VLAN、QoS、ACL、VXLAN 等功能，满足复杂网络环境的需求。
堆叠能力：支持 SummitStack-V400 400Gbps 高速堆叠，最多可堆叠 8 台交换机，扩展网络规模。
安全性特性：支持 802.1X 身份验证、端口安全、DoS 攻击防护等，保障网络安全。
Extreme Networks X590-24X-1Q-2C端口交换机 英文介绍
Extreme Networks X590-24X-1Q-2C Switch
1、 Product Introduction
Extreme Networks X590-24X-1Q-2C is a high-performance 24 port Gigabit/10 Gigabit Ethernet switch designed specifically for enterprise networks and data centers, providing flexible connectivity options and powerful management capabilities to meet the demands of modern networks for high-density access and high-speed data transmission.
2、 Main specifications
Port configuration:
24 10/100/1000BASE-T RJ45 ports
1 10Gb/40Gb QSFP+upstream port
Two 10Gb/25Gb/40Gb/50Gb/100Gb QSFP28 upstream ports
1 10/100/1000BASE-T management port
1 serial console port
Switching capacity: 880 Gbps
Forwarding rate: 714 Mpps
Memory configuration:
2 GB DDR3 ECC memory
4 GB eMMC flash memory
Power requirements:
Supports 770W AC or 1100W DC power modules (modular design)
Fan module: 4 hot swappable fan modules
Size: 44.1 cm (W) x 48.8 cm (D) x 4.35 cm (H)
Weight: Approximately 6.6 kg
3、 Key characteristics
High density port configuration: Provides 24 10/100/1000BASE-T RJ45 ports to meet the access layer requirements of enterprise networks.
High speed uplink: Supports 1 10Gb/40Gb QSFP+uplink port and 2 10Gb/25Gb/40Gb/50Gb/100Gb QSFP28 uplink ports, adapting to different network topologies and bandwidth requirements.
High performance switching capability: With a switching capacity of 880 Gbps and a forwarding rate of 714 Mpps, it ensures high-speed data transmission.
Flexible power and fan configuration: Supports modular power and fan modules, providing redundancy and high availability.
Intelligent management function: Running the ExtremeXOS operating system, supporting Layer 2/Layer 3 switching, VLAN, QoS, ACL, VXLAN and other functions to meet the needs of complex network environments.
Stacking capability: Supports SummitStack-V400 400Gbps high-speed stacking, up to 8 switches can be stacked, expanding network scale.
Security features: Supports 802.1X authentication, port security, DoS attack protection, etc., to ensure network security.
Extreme Networks X590-24X-1Q-2C端口交换机 产品展示
