Extreme Networks SummitStack-V8 控制器模块
一、产品简介
SummitStack-V8 是专为 Summit X460 系列交换机设计的堆叠模块，通过高速 QSFP+ 接口实现交换机之间的堆叠连接，提供高带宽、低延迟的堆叠方案，适合需要高可用性和可扩展性的网络环境。
二、主要规格
端口配置：2 个 QSFP+ 堆叠端口
适用设备：Summit X460 系列交换机
安装位置：Slot B 插槽
堆叠拓扑：支持线性和环形拓扑
最大堆叠数量：最多支持 8 台交换机
连接介质：
支持主动或被动 QSFP+ 光纤直连电缆
支持铜缆或光纤连接
三、关键特性
高带宽堆叠：每个端口提供高达 80 Gbps 带宽
灵活连接：适应机架内和机架间不同部署需求
集中管理：通过 ExtremeXOS 操作系统统一管理堆叠交换机
高可用性：堆叠成员间冗余连接，提高网络可靠性
四、适用场景
数据中心核心或汇聚层
企业多交换机堆叠网络
校园或高密度接入网络
Extreme Networks SUMMITSTACK-V8控制器模块 英文介绍
Extreme Networks SummitStack-V8 Controller Module
1、 Product Introduction
SummitStack-V8 is a stacking module designed specifically for the Summit X460 series switches. It achieves stacking connections between switches through high-speed QSFP+interfaces, providing a high bandwidth, low latency stacking solution that is suitable for network environments that require high availability and scalability.
2、 Main specifications
Port configuration: 2 QSFP+stacked ports
Applicable equipment: Summit X460 series switch
Installation location: Slot B slot
Stacked topology: supports linear and circular topologies
Maximum Stacking Quantity: Supports up to 8 switches
Connection medium:
Support active or passive QSFP+fiber optic direct cable connection
Supports copper or fiber optic connections
3、 Key characteristics
High bandwidth stacking: Each port provides up to 80 Gbps bandwidth
Flexible connectivity: Adapt to different deployment requirements within and between racks
Centralized management: Unified management of stacked switches through the ExtremeXOS operating system
High availability: Redundant connections between stacked members improve network reliability
4、 Applicable scenarios
Data center core or aggregation layer
Enterprise multi switch stacked network
Campus or high-density access network
Extreme Networks SUMMITSTACK-V8控制器模块 产品展示
