Extreme Networks 220-48P-10GE4托管交换机 PDF资料

1.产 品 资 料 介 绍：

Extreme 220-48P-10GE4 托管交换机产品特点

产品简介
Extreme 220-48P-10GE4 是 Extreme Networks 210/220 系列中的一款高性能托管型 Layer 3 交换机，适用于中小型企业和分支机构。它提供高密度千兆端口和高速 10GbE 上行接口，支持 PoE+ 功能，满足办公环境、数据中心和核心网络的需求。

主要特点

1. 端口配置：48 个 10/100/1000BASE-T PoE+ RJ45 端口，支持 IEEE 802.3at，总 PoE 功率约 485W，可为 IP 摄像头、无线 AP、IP 电话等设备供电。

2. 上行接口：4 个 10GBASE-X SFP+ 光纤端口，用于高速链路或网络堆叠。

3. 管理接口：1 个 10/100BASE-T 管理端口和 1 个串行控制台端口，支持远程和本地管理。

4. 性能指标：交换容量约 176 Gbps，转发速率约 130.9 Mpps，MAC 地址表 16,000 条。

5. 堆叠功能：支持多台交换机堆叠为单一逻辑设备，便于集中管理。

6. 电源与散热：内置 485W AC 电源模块，支持热插拔和冗余配置，满 PoE 负载时最大功耗约 485W，热耗散约 392 BTU/h。

7. 尺寸与安装：1U 机架式设计，尺寸约 44.1 cm × 25.4 cm × 4.4 cm，重量约 4.5 kg。

8. 网络功能：支持 Layer 3 静态路由和 RIP，提供 VLAN、链路聚合、生成树协议、ACL 等功能。

9. 管理功能：支持 Extreme Management 系统，实现集中管理和配置。

应用场景

• 企业网络接入层，为办公区域提供稳定连接

• 分支机构网络部署，支持远程管理

• IP 摄像头和无线 AP 供电部署

• 小型数据中心核心交换

• 高性能网络聚合，利用 10GbE 上行端口提升带宽

Extreme Networks 220-48P-10GE4托管交换机 英文介绍

Features of Extreme 220-48P-10GE4 Managed Switch Product

Product Introduction

Extreme 220-48P-10GE4 is a high-performance hosted Layer 3 switch in the Extreme Networks 210/220 series, suitable for small and medium-sized enterprises and branch offices. It provides high-density gigabit ports and high-speed 10GbE uplink interfaces, supports PoE+functionality, and meets the needs of office environments, data centers, and core networks.

Main Features

Port configuration: 48 10/100/1000BASE-T PoE+RJ45 ports, supporting IEEE 802.3at, with a total PoE power of approximately 485W, capable of powering IP cameras, wireless APs, IP phones, and other devices.

Upstream interface: 4 10GBASE-X SFP+fiber ports for high-speed links or network stacking.

Management interface: 1 10/100BASE-T management port and 1 serial console port, supporting remote and local management.

Performance indicators: Switching capacity of approximately 176 Gbps, forwarding rate of approximately 130.9 Mpps, and 16000 MAC address tables.

Stacking function: Supports stacking multiple switches into a single logical device for centralized management.

Power and Heat Dissipation: Built in 485W AC power module, supports hot swapping and redundant configuration, with a maximum power consumption of approximately 485W and heat dissipation of approximately 392 BTU/h under full PoE load.

Size and Installation: Designed with a 1U rack, the dimensions are approximately 44.1 cm x 25.4 cm x 4.4 cm, and the weight is approximately 4.5 kg.

Network function: Supports Layer 3 static routing and RIP, providing VLAN, link aggregation, spanning tree protocol, ACL and other functions.

Management function: Supports Extreme Management system to achieve centralized management and configuration.

Application scenarios

Enterprise network access layer provides stable connectivity for office areas

Branch network deployment, supporting remote management

Deployment of IP cameras and wireless AP power supply

Small data center core exchange

High performance network aggregation, utilizing 10GbE upstream ports to enhance bandwidth

Extreme Networks 220-48P-10GE4托管交换机 产品展示
