AMAT Applied Materials 0190-09368连接器 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
AMAT 0190-09368 连接器（Connector Assembly） 是 Applied Materials 半导体设备中用于信号、电源或控制接口连接的工业级接插件组件。
该部件常用于 PVD（物理气相沉积）、CVD（化学气相沉积）、Etch（刻蚀） 及其他真空工艺设备的主控制柜、加热器模块、磁铁驱动器、传感器接口模块等部位。
其主要功能是实现 设备内部各电子模块之间的可靠电气连接，并保证在高温、低气压、强电磁干扰等苛刻环境下，信号与电源传输稳定、安全。
二、产品技术特点
高可靠性设计
采用工业级金属壳体与耐高温绝缘材料；
防松脱结构，抗震性能强，适合真空设备内部振动环境。
优异的电气性能
低接触电阻（典型值 < 5 mΩ）；
高绝缘耐压性能，可达 500 V～1000 V 级别；
保证信号完整性，减少串扰与干扰。
耐高温与真空兼容性
插针与外壳采用镀镍铜合金或不锈钢材质；
绝缘部分为高性能聚四氟乙烯（PTFE）或氧化铝陶瓷；
适合真空腔体内外连接环境，不产生气体挥发或颗粒。
多通道设计
支持多芯引脚配置（典型为 10 Pin / 20 Pin / 24 Pin / 32 Pin 可选）；
能同时传输电源、模拟信号、控制信号等多路数据。
防护性能强
防护等级可达 IP65–IP67；
抗静电、防尘、防溅液设计，适用于洁净室环境。
快速锁定结构
采用螺纹锁环或卡口锁定（Bayonet）设计；
插拔方便，接触压力均匀，保证长期稳定接触。
模块化兼容性
兼容 AMAT 系列控制模块与驱动模块（如 0190-16633 磁铁驱动器、0190-25423 电源模块等）；
可与标准 MIL-C-5015、Cannon 或 ITT 系列军工级连接器互换。
AMAT Applied Materials 0190-25423直流电源模块 英文介绍
1、 Product Overview
AMAT 0190-09368 Connector Assembly is an industrial grade connector component used in Applied Materials semiconductor equipment for signal, power, or control interface connections.
This component is commonly used in the main control cabinet, heater module, magnet driver, sensor interface module, and other parts of PVD (Physical Vapor Deposition), CVD (Chemical Vapor Deposition), Etch (Etch) and other vacuum process equipment.
Its main function is to achieve reliable electrical connections between various electronic modules inside the device, and ensure stable and safe signal and power transmission in harsh environments such as high temperature, low pressure, and strong electromagnetic interference.
2、 Product Technical Features
High reliability design
Adopting industrial grade metal casing and high-temperature resistant insulation materials;
Anti loosening structure, strong seismic performance, suitable for internal vibration environment of vacuum equipment.
Excellent electrical performance
Low contact resistance (typical value<5 m Ω);
High insulation and voltage resistance performance, up to 500V~1000V level;
Ensure signal integrity and reduce crosstalk and interference.
High temperature resistance and vacuum compatibility
The pins and housing are made of nickel plated copper alloy or stainless steel material;
The insulation part is made of high-performance polytetrafluoroethylene (PTFE) or alumina ceramic;
Suitable for connecting environments inside and outside vacuum chambers, without producing gas evaporation or particles.
Multi channel design
Support multi-core pin configuration (typically 10 Pin/20 Pin/24 Pin/32 Pin optional);
Capable of simultaneously transmitting multiple data channels such as power supply, analog signals, and control signals.
Strong protective performance
The protection level can reach IP65- IP67;
Anti static, dust-proof, and splash proof design, suitable for clean room environments.
Quick locking structure
Adopting a threaded locking ring or Bayonet locking design;
Easy insertion and removal, uniform contact pressure, ensuring long-term stable contact.
Modular compatibility
Compatible with AMAT series control modules and driver modules (such as 0190-16633 magnet driver, 0190-25423 power module, etc.);
Can be interchanged with standard MIL-C-5015, Cannon, or ITT series military grade connectors.
