AMAT Applied Materials 0190-22543网关模块 PDF资料

1.产 品 资 料 介 绍：

AMAT Applied Materials 0190-22543 网关模块

一、产品概述

AMAT 0190-22543 是应用材料公司（Applied Materials）用于半导体设备控制系统的 工业通信网关模块（Industrial Gateway Module）。
其主要功能是作为 设备内部控制网络与上位控制系统（Host/Factory Network）之间的桥梁，实现不同通信协议之间的数据转换、信息汇集与安全传输。

该模块通常用于 Centura、Endura、Producer、P5000 等半导体制造平台，支持设备间与工厂 MES/SCADA 系统的数据交互与监控。

二、产品功能

1. 协议转换与通信桥接

• 支持工业现场总线（如 RS-485、CAN、Modbus 等）与以太网通信协议（Ethernet/IP、TCP/IP）之间的实时转换。

• 实现不同模块（控制器、I/O、传感器、执行器）与上位系统的互通。

2. 数据采集与汇总

• 对设备运行状态、工艺参数、报警信息进行采集与整理。

• 可提供历史数据缓存，保证在网络暂时中断时仍能安全保存信息。

3. 系统安全与隔离

• 内置电气隔离和网络隔离设计，确保设备内部控制系统与工厂网络安全分离。

• 支持防止数据干扰、意外控制命令和网络攻击。

4. 实时监控与诊断

• 提供诊断接口，可监控网络状态、模块状态、数据传输质量。

• 支持 LED 或软件指示，便于现场工程师快速定位问题。

三、产品特点

1. 多协议兼容性

• 支持多种工业通信协议，兼容 AMAT 各类控制模块与 MES/SCADA 系统。

• 可同时处理现场总线和以太网通信，提高数据流通效率。

2. 高可靠性设计

• 工业级元件，适应半导体设备高温、高湿、真空及电磁干扰环境。

• 支持 24/7 连续运行，MTBF 高于工业标准。

3. 模块化与易维护

• 插入式或模块化结构，便于现场安装与更换。

• 带有标准接口，支持快速拆装和现场升级。

4. 安全与电气隔离

• 电源、信号和通信接口均具备隔离措施，保护设备控制系统不受外部网络干扰。

• 提供过压、过流保护和过温保护。

5. 实时数据处理能力

• 高速数据采集和处理，保证工艺参数和控制信号的及时传输。

• 支持批量数据聚合和条件触发报警机制。

AMAT Applied Materials 0190-22543网关模块 英文介绍

AMAT Applied Materials 0190-22543 Gateway Module

1、 Product Overview

AMAT 0190-22543 is an Industrial Gateway Module used by Applied Materials for semiconductor equipment control systems.

Its main function is to serve as a bridge between the internal control network of the device and the host/factory network, enabling data conversion, information aggregation, and secure transmission between different communication protocols.

This module is commonly used in semiconductor manufacturing platforms such as Centura, Endura, Producer, P5000, etc., supporting data exchange and monitoring between devices and factory MES/SCADA systems.

2、 Product Features

Protocol conversion and communication bridging

Support real-time conversion between industrial fieldbus (such as RS-485, CAN, Modbus, etc.) and Ethernet communication protocols (Ethernet/IP, TCP/IP).

Realize the interconnection between different modules (controller, I/O, sensor, actuator) and the upper system.

Data collection and summary

Collect and organize equipment operating status, process parameters, and alarm information.

We can provide historical data caching to ensure the safe storage of information even in the event of a temporary network interruption.

System Security and Isolation

Built in electrical and network isolation design ensures that the internal control system of the equipment is securely separated from the factory network.

Support preventing data interference, unexpected control commands, and network attacks.

Real time monitoring and diagnosis

Provide diagnostic interfaces to monitor network status, module status, and data transmission quality.

Support LED or software indication for on-site engineers to quickly locate problems.

3、 Product Features

Multi protocol compatibility

Supports multiple industrial communication protocols and is compatible with various AMAT control modules and MES/SCADA systems.

It can simultaneously handle fieldbus and Ethernet communication, improving data flow efficiency.

High reliability design

Industrial grade components that are suitable for high temperature, high humidity, vacuum, and electromagnetic interference environments in semiconductor equipment.

Supports 24/7 continuous operation with MTBF higher than industry standards.

Modular and easy to maintain

Plug in or modular structure, convenient for on-site installation and replacement.

Equipped with standard interfaces, supporting quick disassembly and on-site upgrades.

Safety and electrical isolation

The power supply, signal, and communication interfaces are all equipped with isolation measures to protect the equipment control system from external network interference.

Provide overvoltage, overcurrent protection, and over temperature protection.

Real time data processing capability

High speed data acquisition and processing ensure timely transmission of process parameters and control signals.

Support batch data aggregation and conditional trigger alarm mechanism.

AMAT Applied Materials 0190-22543网关模块 产品展示

3.其他产品

T3N225断路器
TRICONEX 8310  电源模块
1TGE120011R1111 控制器模块

4.其他英文产品

SY-61025004RA SY-61025001RA Output card
ALSTOM V4561983-0100 V4559856 Control card
V7768-322001 combustion engine card

本篇文章出自瑞昌明盛自动化设备有限公司官网，转载请附上此链接:http://www.jiangxidcs

品牌：AMAT Applied Materials

型号：0190-22543网关模块

质保：一年

成色：全新/二手

优势产品：ABB、GE、FOXBORO、TRICONEX、BENTLY、A-B、MOTOROLA、HONEYWELL 、SCHNEIDER

                    WOODWARD、EMERSON、RELIANCE、DEIF、NI、XYVOM等

特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

应用行业：广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、烟草、塑胶机械、电力、水利、水处理/环保、市政工程、锅炉供暖、能源、输配电等

快递方式：国内顺丰、德邦、京东快递包邮，按照实际报价货期发货
