AMAT Applied Materials 0120-90622控制器 PDF资料

1.产 品 资 料 介 绍：

AMAT 0120-90622 控制器

产品概述

AMAT 0120-90622 控制器是 Applied Materials 半导体设备中的关键控制单元，主要用于管理工艺腔体、气体面板、电源系统等子模块的运行。它通过高速信号处理与多通道输入/输出接口，实现对复杂工艺参数的精准控制和实时监测，确保制程的稳定性与一致性。该模块通常安装在设备主控架构中，是系统逻辑与执行控制的核心。

技术参数（推测通用特性）

• 控制功能：支持数字量、模拟量输入输出，具备工艺参数采集与逻辑控制能力

• 处理能力：内置高性能处理器或可编程逻辑电路，满足半导体工艺的实时响应要求

• 接口支持：可与气体面板、真空泵、射频电源、温控单元等设备进行通信与联动

• 电源特性：低压直流供电（典型 +24VDC），带过压与过流保护

• 稳定性：符合洁净室环境使用要求，具备抗干扰与长时间运行能力

应用场景

1. 半导体工艺设备核心控制

• 用于 CVD、PVD、ALD、刻蚀、清洗等设备的子系统协调

• 负责工艺气体、温度、真空度、射频功率等关键参数的控制

2. 设备安全与互锁控制

• 与继电器模块、气体面板分析模块配合，执行安全互锁与保护功能

• 避免在非安全状态下运行设备

3. 工艺参数精密调节

• 提供实时闭环控制，保持工艺条件的稳定与重复性

• 确保薄膜沉积、刻蚀轮廓等结果的一致性

4. 运行数据采集与诊断

• 实时采集工艺与设备运行数据

• 支持预测性维护，提升设备稼动率

AMAT Applied Materials 0120-90622控制器 英文资料：

AMAT 0120-90622 Controller

Product Overview

The AMAT 0120-90622 controller is a key control unit in Applied Materials semiconductor equipment, mainly used to manage the operation of sub modules such as process chambers, gas panels, and power systems. It achieves precise control and real-time monitoring of complex process parameters through high-speed signal processing and multi-channel input/output interfaces, ensuring process stability and consistency. This module is usually installed in the device's main control architecture and is the core of system logic and execution control.

Technical parameters (inferred general characteristics)

Control function: Supports digital and analog input and output, with the ability to collect process parameters and control logic

Processing capability: Built in high-performance processor or programmable logic circuit to meet the real-time response requirements of semiconductor processes

Interface support: Can communicate and link with devices such as gas panels, vacuum pumps, RF power supplies, temperature control units, etc

Power characteristics: Low voltage DC power supply (typical+24VDC), with overvoltage and overcurrent protection

Stability: Meets the requirements for use in clean room environments, with anti-interference and long-term operation capabilities

Application scenarios

Core control of semiconductor process equipment

Subsystem coordination for CVD, PVD, ALD, etching, cleaning and other equipment

Responsible for controlling key parameters such as process gas, temperature, vacuum degree, RF power, etc

Equipment safety and interlock control

Cooperate with relay module and gas panel analysis module to perform safety interlock and protection functions

Avoid operating equipment in non safe conditions

Precise adjustment of process parameters

Provide real-time closed-loop control to maintain stability and repeatability of process conditions

Ensure consistency of results such as thin film deposition and etching profiles

Run data collection and diagnosis

Real time collection of process and equipment operation data

Support predictive maintenance to improve equipment utilization rate

AMAT Applied Materials 0120-90622控制器 产品展示
