AMAT Applied Materials 0021-21840联锁连接器 PDF资料
1.产 品 资 料 介 绍：
产品概述
AMAT 0021-21840 是 Applied Materials 半导体设备中的 联锁连接器（Interlock Connector）。
该连接器主要用于 安全联锁和信号连接，确保设备在操作、维护或模块拆装过程中，系统能够正确识别状态并触发保护机制，从而保障设备和操作人员安全。
技术参数（推断性质）
类型：联锁连接器（Interlock Connector / Safety Interlock Connector）。
功能：
提供电气信号通路，用于联锁检测和状态反馈。
与设备控制系统联动，实现模块插拔或门盖开关状态监控。
触发安全联锁逻辑，当联锁条件未满足时阻止设备运行。
接口类型：多针插头或插座接口，与控制模块或安全系统连接。
安装位置：机台控制柜、模块槽位或安全门/盖接口位置。
特点：高可靠性、耐磨损、抗干扰能力强，适应半导体洁净环境和长期使用。
应用场景
设备安全联锁
检测门盖、模块或机台关键部件是否正确安装或关闭，防止设备在不安全状态下运行。
模块连接识别
在模块化 PCB 或控制系统中，确认模块已正确连接并通电，保证系统运行可靠。
工艺保护
联锁信号反馈至控制器，确保工艺执行前各安全条件满足，避免晶圆或设备损坏。
维护与升级支持
联锁连接器设计允许快速拆装和检查，便于设备维护和模块更换。
产品优势
高可靠性：确保安全联锁功能长期稳定运行。
耐磨损和抗干扰：适应频繁插拔和半导体设备电磁环境。
模块化设计：便于安装、拆卸及更换，降低停机时间。
安全性高：防止设备在不安全状态下运行，保护人员和工艺安全。
兼容性好：专为 AMAT 系列设备设计，与控制系统和模块无缝匹配。
AMAT Applied Materials 0021-21840联锁连接器 英文资料：
Product Overview
AMAT 0021-21840 is an interlock connector used in Applied Materials semiconductor equipment.
This connector is mainly used for safety interlocking and signal connection, ensuring that the system can correctly identify the status and trigger protection mechanisms during equipment operation, maintenance, or module disassembly, thereby ensuring the safety of equipment and operators.
Technical parameters (inferred properties)
Type: Interlock Connector/Safety Interlock Connector.
Function:
Provide electrical signal pathways for interlock detection and status feedback.
Integrate with the device control system to achieve module insertion and removal or door cover switch status monitoring.
Trigger safety interlock logic to prevent equipment operation when interlock conditions are not met.
Interface type: Multi pin plug or socket interface, connected to control module or safety system.
Installation location: machine control cabinet, module slot or safety door/cover interface position.
Features: High reliability, wear resistance, strong anti-interference ability, suitable for semiconductor clean environment and long-term use.
Application scenarios
Equipment safety interlock
Check whether the door cover, module or key components of the machine are correctly installed or closed to prevent the equipment from operating in an unsafe state.
Module connection recognition
In modular PCB or control systems, ensure that the modules are correctly connected and powered on to ensure reliable system operation.
Process protection
The interlocking signal is fed back to the controller to ensure that all safety conditions are met before the process is executed, avoiding damage to the wafer or equipment.
Maintenance and upgrade support
The interlocking connector design allows for quick disassembly and inspection, facilitating equipment maintenance and module replacement.
Product advantages
High reliability: Ensure long-term stable operation of safety interlock function.
Wear resistance and anti-interference: Suitable for frequent insertion and removal and electromagnetic environment of semiconductor equipment.
Modular design: easy to install, disassemble, and replace, reducing downtime.
High safety: prevent equipment from operating in unsafe conditions, protect personnel and process safety.
Good compatibility: designed specifically for AMAT series devices, seamlessly matching with control systems and modules.
AMAT Applied Materials 0021-21840联锁连接器 产品展示
