Motorola MVME923 1982背板模块 PDF资料
1.产 品 资 料 介 绍：
产品概述
Motorola MVME923 1982 是一款 VME 总线背板模块，用于 MVME 系列单板计算机和功能模块之间的互联。它提供标准化的 VME 总线连接接口，支持 数据、地址和控制信号的高速传输，确保系统各板件之间的可靠通信与同步。该模块是构建 VME 系统的基础硬件之一。
技术参数
类型：VME 总线背板模块
兼容性：支持 MVME 系列 CPU 模块及 I/O 模块
槽位数：常见配置为 6~21 槽（具体型号可根据系统机箱调整）
总线标准：
支持 VME64/VMEbus 标准
地址模式：A16/A24/A32
数据模式：D08/D16/D32
信号完整性：采用工业级 PCB 设计，确保信号传输稳定
电源分配：通过背板提供 +5V、±12V 等标准电源给模块
尺寸与安装：符合 VME 机箱尺寸规范，易于模块化安装
应用场景
工业自动化系统：作为 MVME 单板计算机与 I/O 模块的互联平台
嵌入式控制平台：为多模块嵌入式系统提供数据与控制总线
测试与测量系统：在仪器设备中实现各模块之间高速同步与数据传输
通信系统：用于 VME 架构的交换机、基站和控制节点
军事与航空：用于嵌入式指挥控制系统的模块化互联
Motorola MVME923 1982背板模块 英文资料：
Product Overview
Motorola MVME923 1982 is a VME bus backplane module used for interconnecting MVME series single board computers and functional modules. It provides standardized VME bus connection interfaces, supporting high-speed transmission of data, address, and control signals, ensuring reliable communication and synchronization between system components. This module is one of the fundamental hardware components for building a VME system.
Technical Specifications
Type: VME bus backplane module
Compatibility: Supports MVME series CPU modules and I/O modules
Slot number: The common configuration is 6-21 slots (specific models can be adjusted according to the system chassis)
Bus standard:
Support VME64/VMEbus standards
Address mode: A16/A24/A32
Data mode: D08/D16/D32
Signal integrity: Adopting industrial grade PCB design to ensure stable signal transmission
Power distribution: Standard power sources such as+5V and ± 12V are provided to the module through the backplane
Size and Installation: Compliant with VME chassis size specifications, easy to modularize installation
Application scenarios
Industrial Automation Systems: As an Interconnected Platform between MVME Single Board Computers and I/O Modules
Embedded Control Platform: Provides data and control bus for multi module embedded systems
Testing and Measurement System: Achieving high-speed synchronization and data transmission between modules in instrument equipment
Communication System: Switches, Base Stations, and Control Nodes for VME Architecture
Military and Aviation: Modular Interconnection for Embedded Command and Control Systems
Motorola MVME923 1982背板模块 产品展示
