Motorola VME-340B 处理器 PCB 卡 PDF资料
1.产 品 资 料 介 绍：
Motorola VME-340B 处理器 PCB 卡
产品概述
Motorola VME-340B 是一款基于 VMEbus 架构的处理器 PCB 卡（Processor PCB Card），用于工业嵌入式系统和 VME 总线计算平台。该模块集成了 CPU、内存、总线接口和控制逻辑，可作为系统核心计算单元，实现高速数据处理、实时控制和与其他 VME 扩展模块的数据交互。VME-340B PCB 卡常用于工业自动化、测试测量、通信和科研系统中。
技术参数
处理器：Motorola MC68EC030/MC68030 系列 CPU
内存：
RAM：2 MB – 8 MB 可扩展
ROM/Flash：用于固件与引导程序
NVRAM：带实时时钟功能
总线接口：VMEbus 标准，支持 16/32 位数据传输
I/O 接口：
多路串行接口（RS-232/RS-422）
并行接口
定时器与看门狗功能
控制功能：
总线仲裁和 DMA 数据传输
中断管理和状态监控
系统兼容性：支持 VxWorks、pSOS 等嵌入式实时操作系统
工作环境：工业级设计，适应宽温和高干扰环境
应用场景
工业自动化控制
控制生产线和工业设备的数据采集与执行。
机床与运动控制系统
支持多轴同步控制、脉冲输出和伺服驱动管理。
测试与测量系统
数据采集、实验设备控制及信号处理。
嵌入式控制与通信系统
嵌入式网络节点及协议处理。
能源与电力系统
实时监控和控制发电、变电、配电系统。
Motorola VME-340B 处理器 PCB 卡 英文资料：
Motorola VME-340B processor PCB card
Product Overview
Motorola VME-340B is a processor PCB card based on the VMEbus architecture, used for industrial embedded systems and VME bus computing platforms. This module integrates CPU, memory, bus interface, and control logic, and can serve as the core computing unit of the system, achieving high-speed data processing, real-time control, and data interaction with other VME expansion modules. The VME-340B PCB card is commonly used in industrial automation, testing and measurement, communication, and scientific research systems.
Technical Specifications
Processor: Motorola MC68EC030/MC68030 series CPU
Memory:
RAM: 2 MB -8 MB expandable
ROM/Flash: Used for firmware and boot programs
NVRAM: with real-time clock function
Bus interface: VMEbus standard, supports 16/32-bit data transmission
I/O interface:
Multi channel serial interface (RS-232/RS-422)
Parallel Interface
Timer and watchdog function
Control function:
Bus arbitration and DMA data transfer
Interrupt management and status monitoring
System compatibility: Supports embedded real-time operating systems such as VxWorks and pSOS
Work environment: Industrial grade design, suitable for wide temperature and high interference environments
Application scenarios
industrial automation control
Control the data collection and execution of production lines and industrial equipment.
Machine Tool and Motion Control System
Support multi axis synchronous control, pulse output, and servo drive management.
Testing and Measurement System
Data collection, experimental equipment control, and signal processing.
Embedded Control and Communication System
Embedded network nodes and protocol processing.
Energy and Power Systems
Real time monitoring and control of power generation, transformation, and distribution systems.
