3BHB004791R0101配置手册,ABB励磁模块
程序块最多512个程序块。块的最大大小为128KB。
%I和%Q:32Kbits用于离散%AI和%AQ：最多可配置32Kwords%W： 可配置到最大可用用户RAM托管内存（符号和输入/输出变量组合）：可配置高达10 MB以太网接口规范基于Web的数据监控多达16个Web服务器和FTP连接（组合）此版本的重要产品信息以太网固件版本6.20增加了SNTP对本地时区和夏令时的支持。
3BHB004791R0101配置手册有关详细信息，请参阅第5页的“固件版本6.20中的新以太网功能和增强”。对于在中解决的问题此版本，请参阅第16页的“在固件版本6.20中解决的以太网问题”。
硬件版本-Jx更正硬件ID，以便在与智能电池一起使用时启用低电池检测。重要提示：建议用户将station manager密码更改为默认密码以外的密码
暗语当station manager密码设置为时，将禁用对远程station manager的访问默认密码。
GE Intelligent Platform建议禁用未使用的FTP服务器和/或Web服务器连接。对于详见第19页。更新CPE030和CPE040可以使用Winloader固件现场升级到CPU版本6.75和以太网版本6.20升级实用程序和以下升级工具包之一。LREAL数据类型支持需要5.50或更高版本的工具包。
当PACSystems CPU运行时，需要C Toolkit Release 5.00 Build 16C1或更高版本包含固件版本5.00或更高版本。注意：使用早于5.00 Build 16C1的C Toolkit版本构建的C块必须使用更新的工具包版本重新编译，以便与CPU固件一起使用5.00或更高版本。
Series 90 Toolkit（IC641SWP709/719）与PACSystems不兼容。PACSystems RX7i支持90-70系列扩展机架。PACSystems RX7i CPU和RX7i以太网模块不在90-70系列中运行支架
90-70系列主机架兼容性
90-70系列主机架不能用于PACSystems RX7i系统。PACSystems RX7i CPU和RX7i以太网模块不在90-70系列中运行支架
Program blocks Up to 512 program blocks. Maximum size for a block is 128KB.
Memory
(For a detailed listing of memory areas, refer to
the CPU Reference Manual, GFK-2222.)
%I and %Q: 32Kbits for discrete
%AI and %AQ: configurable up to 32Kwords
%W: configurable up to the maximum available user RAM
Managed memory (Symbolic and I/O variables combined):
configurable up to 10 Mbytes
Ethernet Interface Specifications
Web-based data monitoring Up to 16 web server and FTP connections (combined)Important Product Information for this Release
Ethernet Firmware version 6.20 adds support in SNTP for local time zones and daylight savings.
For details, see “New Ethernet Features and Enhancements in Firmware Version 6.20” on page 5. For problems resolved in
this release, see “Ethernet Problems Resolved in Firmware Version 6.20” on page 16.
Hardware version -Jx corrects the hardware ID to enable low battery detection when used with a smart battery.
Important Note: It is recommended that the user change the station manager password to a password other than the default
password. Access to remote station manager will be disabled when the station manager password is set to
the default password.
GE Intelligent Platforms recommends disabling FTP server and/or Web server connections if not used. For
details, see page 19.Updates
The CPE030 and CPE040 can be field upgraded to CPU version 6.75 and Ethernet version 6.20 using the Winloader firmware
upgrade utility and one of the following upgrade kits. Toolkit Release 5.50 or later is required for LREAL data type support.
C Toolkit Release 5.00 Build 16C1 or later is required when the PACSystems CPU
contains firmware Release 5.00 or later.
Notes: C blocks that were built using C Toolkit versions earlier than 5.00 Build 16C1
must be recompiled using a newer toolkit version for use with CPU firmware
release 5.00 or higher.
The Series 90 Toolkit (IC641SWP709/719) is not compatible with PACSystems.Series 90-70 expansion racks are supported by the PACSystems RX7i.
PACSystems RX7i CPUs and the RX7i Ethernet Module do not operate in a Series 90-70
rack.
Series 90-70 Main rack
compatibility
Series 90-70 Main Racks cannot be used in a PACSystems RX7i system.
PACSystems RX7i CPUs and the RX7i Ethernet Module do not operate in a Series 90-70
