GIDINGS&LEWIS  502-03641-00输入输出模块 PDF资料

1.产 品 资 料 介 绍：

Giddings & Lewis 502-03641-00 输入输出模块

产品概述

502-03641-00 是 Giddings & Lewis 工业控制系统中的 输入/输出（I/O）模块，属于其数控与自动化平台的功能扩展单元。该模块主要负责外部信号的采集与输出，为控制器与现场设备之间提供可靠接口。

技术特性

• 模块类型：数字量输入/输出模块

• 功能定位：

• 接收外部传感器、开关量等输入信号

• 输出控制指令至执行机构（如继电器、伺服驱动、指示装置）

• 设计特点：

• 工业级多层 PCB，具备抗干扰与高可靠性

• 支持并行多路输入输出，提升控制系统扩展性

• 插卡式设计，便于与控制机架快速集成

应用场景

1. CNC 数控机床：用于采集机床操作面板、限位开关、工件检测信号，并输出控制指令至伺服系统或辅助设备。

2. 自动化生产线：实现传感器输入、气动元件、执行器等的集中控制。

3. 运动控制系统：与伺服驱动器、步进电机控制模块配合，完成复杂工序的逻辑控制。

4. 工业设备改造：作为控制系统的扩展模块，增强老旧设备的输入输出能力。

产品优势

• 高兼容性：适用于 Giddings & Lewis 多种控制平台与机架系统。

• 稳定可靠：长时间运行下保持信号完整性，适应高噪声工业环境。

• 模块化维护：可单独更换，降低停机时间和维修成本。

• 扩展性强：支持多点输入输出，适合复杂控制任务。

英文资料：

Giddings&Lewis 502-03641-00 Input/Output Module

Product Overview

502-03641-00 is an input/output (I/O) module in the Giddings&Lewis industrial control system, which belongs to the functional expansion unit of its CNC and automation platform. This module is mainly responsible for the collection and output of external signals, providing a reliable interface between the controller and field devices.

Technical Characteristics

Module type: Digital input/output module

Functional positioning:

Receive input signals from external sensors, switches, etc

Output control instructions to the executing mechanism (such as relays, servo drives, indicator devices)

Design features:

Industrial grade multi-layer PCB with anti-interference and high reliability

Support parallel multi-channel input and output to enhance the scalability of the control system

Plug in card design for quick integration with control racks

Application scenarios

CNC machine tools: used to collect signals from machine operation panels, limit switches, and workpiece detection, and output control commands to servo systems or auxiliary equipment.

Automated production line: achieve centralized control of sensor inputs, pneumatic components, actuators, etc.

Motion control system: In conjunction with servo drivers and stepper motor control modules, it completes the logical control of complex processes.

Industrial equipment renovation: As an extension module of the control system, it enhances the input and output capabilities of old equipment.

Product advantages

High compatibility: Suitable for various control platforms and rack systems of Giddings&Lewis.

Stable and reliable: Maintain signal integrity during long-term operation and adapt to high noise industrial environments.

Modular maintenance: can be replaced separately, reducing downtime and maintenance costs.

Strong scalability: Supports multi-point input and output, suitable for complex control tasks.

2.产      品      展      示
