Giddings & Lewis 401-34201-13 DS100 Centurion 伺服驱动器

产品概述

401-34201-13 属于 Giddings & Lewis DS100 系列伺服驱动器，配套 Centurion 控制平台使用。该驱动器用于控制无刷交流伺服电机，具备高响应速度与精确控制能力，是数控系统中的核心驱动单元。

技术参数（典型特征）

• 输入电源：三相 AC，常见为 230V 或 460V 工业电源

• 驱动类型：无刷 AC 伺服驱动器

• 控制方式：速度环、位置环、转矩控制模式

• 输出功率范围：适配中小功率伺服电机（通常在 1–7 kW 区间）

• 保护功能：过压、欠压、过流、过温保护

应用场景

1. CNC 数控机床：作为进给轴或主轴伺服驱动器，保障机床在加工过程中的速度与位置精度。

2. 自动化生产线：用于装配、包装、搬运等自动化设备的电机控制。

3. 工业机器人：为关节伺服电机提供稳定驱动，实现精准运动控制。

4. 专用设备：在纺织机械、印刷机械、电子制造设备中，提供高动态响应驱动。

产品优势

• 高动态性能：快速响应，满足复杂轨迹和高速定位要求。

• 可靠性强：工业级设计，支持长时间连续工作。

• 模块化结构：便于与 Centurion 控制器集成，简化系统架构。

• 安全性好：具备完善的保护功能，减少设备损坏风险。

• 维护性佳：可进行检测、维修与替换，延长整机寿命。

英文资料：

Giddings&Lewis 401-34201-13 DS100 Centurion Servo Drive

Product Overview

401-34201-13 belongs to the Giddings&Lewis DS100 series servo drive and is used in conjunction with the Centurion control platform. This driver is used to control brushless AC servo motors, with high response speed and precise control capability, and is the core driving unit in CNC systems.

Technical parameters (typical features)

Input power supply: three-phase AC, commonly 230V or 460V industrial power supply

Drive type: Brushless AC servo drive

Control mode: speed loop, position loop, torque control mode

Output power range: Suitable for small and medium power servo motors (usually in the range of 1-7 kW)

Protection functions: overvoltage, undervoltage, overcurrent, and over temperature protection

Application scenarios

CNC machine tool: As a feed axis or spindle servo driver, it ensures the speed and position accuracy of the machine tool during the machining process.

Automated production line: used for motor control of automated equipment such as assembly, packaging, and handling.

Industrial robots: provide stable driving for joint servo motors to achieve precise motion control.

Specialized equipment: Provides high dynamic response drive in textile machinery, printing machinery, and electronic manufacturing equipment.

Product advantages

High dynamic performance: Fast response, meeting complex trajectory and high-speed positioning requirements.

Strong reliability: Industrial grade design, supporting long-term continuous operation.

Modular structure: facilitates integration with Centurion controllers and simplifies system architecture.

Good security: equipped with comprehensive protection functions to reduce the risk of equipment damage.

Good maintainability: capable of inspection, repair, and replacement, extending the lifespan of the entire machine.
