GIDINGS&LEWIS  401-34205-21伺服驱动器 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 401-34205-21 伺服驱动器

产品概述

401-34205-21 是 Giddings & Lewis 系统中的 伺服驱动器（Servo Drive），用于接收控制器或 CPU 模块的指令信号，调节伺服电机的速度、位置和力矩，实现精确运动控制。该模块是高精度自动化系统中不可或缺的执行单元。

产品特点

1. 精确位置和速度控制

• 支持闭环控制，实现高精度的速度、位置和力矩调节。

2. 高响应性能

• 快速响应控制信号，保证伺服电机动作实时、平稳。

3. 兼容多种电机

• 可驱动交流伺服电机、直流伺服电机或步进电机，适应不同系统需求。

4. 保护功能完善

• 内置过流、过压、过热及短路保护，保障设备安全。

5. 模块化设计

• 插拔式结构，便于安装、维护和系统扩展。

6. 状态指示功能

• LED 或信号指示，便于监控工作状态和排查故障。

7. 高可靠性

• 工业级设计，耐高温、抗振动、抗电磁干扰，适应复杂工业环境。

应用领域

1. 数控机床（CNC）

• 驱动机床主轴、进给轴及刀具，实现高精度加工与自动化控制。

2. 自动化生产线

• 控制输送系统、装配机械及分拣设备，实现生产线精准运动控制。

3. 机器人系统

• 控制机械臂或多轴机器人，实现高精度、同步运动和闭环控制。

4. 装配与检测设备

• 驱动工件搬运装置、检测仪器或装配机构，实现动作精准与流程同步。

5. 过程控制系统

• 控制阀门、泵及其他执行机构，实现连续、稳定的工业自动化操作。

6. 实验与测试平台

• 驱动实验台或测试设备的运动部分，实现精确的自动化实验和数据采集。

英文资料：

GIDINGS&LEWIS 401-34205-21 servo drive

Product Overview

401-34205-21 is a servo drive in the Giddings&Lewis system, used to receive command signals from the controller or CPU module, adjust the speed, position, and torque of the servo motor, and achieve precise motion control. This module is an indispensable execution unit in high-precision automation systems.

Product Features

Accurate position and speed control

Support closed-loop control to achieve high-precision speed, position, and torque adjustment.

High responsiveness performance

Quickly respond to control signals to ensure real-time and smooth operation of servo motors.

Compatible with multiple motors

Can drive AC servo motors, DC servo motors, or stepper motors to meet different system requirements.

Complete protection function

Built in overcurrent, overvoltage, overheating, and short circuit protection to ensure equipment safety.

modular design

Plug in structure, easy to install, maintain, and expand the system.

Status indication function

LED or signal indication, convenient for monitoring work status and troubleshooting.

high reliability

Industrial grade design, high temperature resistance, vibration resistance, electromagnetic interference resistance, suitable for complex industrial environments.

Application field

Numerical Control Machine Tool (CNC)

Drive the spindle, feed axis, and cutting tools of the machine tool to achieve high-precision machining and automation control.

Automatic production line

Control the conveying system, assembly machinery, and sorting equipment to achieve precise motion control of the production line.

robot system

Control robotic arms or multi axis robots to achieve high-precision, synchronous motion, and closed-loop control.

Assembly and testing equipment

Drive workpiece handling devices, testing instruments, or assembly mechanisms to achieve precise actions and synchronized processes.

process control system

Control valves, pumps, and other actuators to achieve continuous and stable industrial automation operations.

Experimental and testing platform

Drive the moving parts of the experimental platform or testing equipment to achieve precise automated experiments and data collection.

2.产      品      展      示
