GIDINGS&LEWIS 501-03273-01输入板 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 501-03273-01 输入板

产品概述

501-03273-01 是 Giddings & Lewis 系统中的 工业输入板（Input Board），用于接收来自现场开关、传感器或其他数字/模拟信号设备的输入信号，并将其传递给 CPU 或控制器模块，实现对工业设备状态的监控和数据采集。

产品特点

1. 多通道输入

• 支持多路数字或模拟信号输入，方便集中采集设备状态。

2. 信号隔离设计

• 内部电路与系统控制信号隔离，提高抗干扰能力和信号稳定性。

3. 快速响应

• 实时采集输入信号，保证控制系统能迅速对现场状态做出反应。

4. 模块化结构

• 插拔式设计，便于安装、替换和系统扩展。

5. 状态指示功能

• LED 或指示灯显示每路输入的状态，方便调试与维护。

6. 高可靠性

• 工业级设计，耐高温、抗振动、抗电磁干扰，适应严苛工业环境。

7. 兼容性强

• 可与 Giddings & Lewis 系列 CPU、控制器、输出模块及其他 I/O 模块无缝配合。

应用领域

1. 数控机床（CNC）

• 接收限位开关、刀具状态、急停按钮等信号，实现机床位置和安全监控。

2. 自动化生产线

• 采集生产线传感器、开关状态，实现生产流程控制和设备状态监测。

3. 机器人系统

• 接收机械臂限位开关、传感器和安全开关信号，实现闭环运动控制。

4. 装配与检测设备

• 采集工件状态、检测信号及工位开关，实现精准操作和流程控制。

5. 过程控制系统

• 在化工、电力、冶金等工业现场，采集阀门、泵及传感器信号，实现自动化控制和监测。

6. 实验与测试平台

• 接收实验台或测试设备的输入信号，实现自动化操作和数据采集。

英文资料：

GIDINGS&LEWIS 501-03273-01 Input Board

Product Overview

501-03273-01 is an industrial input board in the Giddings&Lewis system, used to receive input signals from on-site switches, sensors, or other digital/analog signal devices, and transmit them to the CPU or controller module to monitor and collect data on the status of industrial equipment.

Product Features

Multi channel input

Supports multiple digital or analog signal inputs, facilitating centralized collection of device status.

Signal isolation design

Internal circuits are isolated from system control signals to improve anti-interference ability and signal stability.

quick response

Real time collection of input signals ensures that the control system can quickly respond to on-site conditions.

Modular structure

Plug in design, easy to install, replace, and expand the system.

Status indication function

LED or indicator lights display the status of each input for easy debugging and maintenance.

high reliability

Industrial grade design, high temperature resistance, vibration resistance, electromagnetic interference resistance, suitable for harsh industrial environments.

Strong compatibility

It can seamlessly integrate with Giddings&Lewis series CPUs, controllers, output modules, and other I/O modules.

Application field

Numerical Control Machine Tool (CNC)

Receive signals such as limit switches, tool status, emergency stop buttons, etc., to achieve machine position and safety monitoring.

Automatic production line

Collect sensor and switch status on the production line to achieve production process control and equipment status monitoring.

robot system

Receive signals from limit switches, sensors, and safety switches of the robotic arm to achieve closed-loop motion control.

Assembly and testing equipment

Collect workpiece status, detection signals, and workstation switches to achieve precise operation and process control.

process control system

Collect signals from valves, pumps, and sensors in industrial sites such as chemical, power, and metallurgical industries to achieve automated control and monitoring.

Experimental and testing platform

Receive input signals from experimental benches or testing equipment to achieve automated operations and data acquisition.

2.产      品      展      示
