GIDINGS&LEWIS 502-03588-02插槽模块 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 502-03588-02 插槽模块

产品概述

502-03588-02 是 Giddings & Lewis 系统中的 插槽模块（Slot Module），用于在系统机架中提供标准化插槽接口，以便安装和互联其他功能模块（如 CPU 模块、I/O 模块、通信模块或伺服驱动模块）。该模块实现电源分配、信号路由和模块间连接，是控制系统模块化和扩展的核心组件。

产品特点

1. 模块化设计

• 标准化插槽结构，支持快速安装、拆卸和系统扩展。

2. 稳定电源分配

• 为插入的各功能模块提供可靠电源，保证系统稳定运行。

3. 信号互联能力

• 提供模块间数据和控制信号的可靠连接，确保系统通信畅通。

4. 兼容性强

• 与 Giddings & Lewis 系列 CPU、I/O、控制器、通信模块及伺服模块兼容。

5. 可靠性高

• 工业级设计，耐高温、抗振动，适应恶劣工作环境。

6. 易于维护

• 插拔式结构便于更换模块，减少系统停机时间。

7. 可扩展性强

• 允许根据控制系统需求灵活增加或更换模块，实现功能扩展。

应用领域

1. 数控机床系统（CNC）

• 为 CPU、I/O、编码器及伺服控制模块提供标准化安装和互联接口。

2. 自动化生产线

• 支持生产线控制系统的模块化布置，实现集中控制与快速维护。

3. 机器人控制系统

• 提供多轴运动控制模块的安装和互联，实现闭环协调控制。

4. 过程控制系统

• 在化工、冶金、电力等工业领域，为各类输入/输出和控制模块提供可靠接口。

5. 实验与测试设备

• 用于实验台或测试装置的模块化安装和快速更换功能模块。

6. 装配与检测设备

• 提供模块化布置方案，使控制和传感模块易于安装和维护。

英文资料：

GIDINGS&LEWIS 502-03588-02 slot module

Product Overview

502-03588-02 is a slot module in the Giddings&Lewis system, used to provide standardized slot interfaces in the system rack for installing and interconnecting other functional modules such as CPU modules, I/O modules, communication modules, or servo drive modules. This module implements power distribution, signal routing, and inter module connections, and is the core component of modular and extended control systems.

Product Features

modular design

Standardized slot structure, supporting quick installation, disassembly, and system expansion.

Stable power distribution

Provide reliable power supply for the inserted functional modules to ensure stable system operation.

Signal interconnection capability

Provide reliable connections for data and control signals between modules to ensure smooth system communication.

Strong compatibility

Compatible with Giddings&Lewis series CPUs, I/O, controllers, communication modules, and servo modules.

high reliability

Industrial grade design, high temperature resistance, vibration resistance, and adaptability to harsh working environments.

easy to maintain

The plug-in structure facilitates module replacement and reduces system downtime.

Strong scalability

Allow flexible addition or replacement of modules according to control system requirements to achieve functional expansion.

Application field

Numerical Control Machine Tool System (CNC)

Provide standardized installation and interconnection interfaces for CPU, I/O, encoder, and servo control modules.

Automatic production line

Support modular layout of production line control systems to achieve centralized control and rapid maintenance.

Robot control system

Provide installation and interconnection of multi axis motion control modules to achieve closed-loop coordinated control.

process control system

Provide reliable interfaces for various input/output and control modules in industrial fields such as chemical engineering, metallurgy, and power.

Experimental and testing equipment

Modular installation and quick replacement of functional modules for experimental benches or testing devices.

Assembly and testing equipment

Provide modular layout solutions to make the control and sensing modules easy to install and maintain.

2.产      品      展      示
