GIDINGS&LEWIS DS2100伺服系统驱动模块 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS DS2100 伺服系统驱动模块

产品概述

DS2100 是 Giddings & Lewis 系统中的 伺服驱动模块，用于控制伺服电机的运动和位置。它接收来自控制器或 CPU 模块的控制信号，输出高精度电流/电压给伺服电机，实现快速响应、精确定位和闭环运动控制。

产品特点

1. 高精度伺服控制

• 支持位置、速度和力矩闭环控制，实现高精度运动控制。

2. 快速响应能力

• 高速处理控制信号，满足动态加工或自动化生产的实时控制需求。

3. 稳定可靠

• 工业级设计，耐高温、抗振动、抗干扰，适合恶劣环境使用。

4. 兼容性强

• 可与 Giddings & Lewis 系列 CPU、控制器、编码器模块等系统模块无缝配合。

5. 模块化设计

• 插拔式结构，便于安装、维护和系统扩展。

6. 多保护功能

• 内置过流、过压、短路保护，保证电机与驱动模块安全运行。

7. 可编程参数

• 支持根据不同电机和负载调节控制参数，实现优化性能。

8. 信号接口完善

• 提供位置反馈接口、模拟/数字输入输出接口，方便系统集成。

应用领域

1. 数控机床（CNC）

• 控制主轴或进给轴伺服电机，实现高精度加工和自动化操作。

2. 自动化生产线

• 驱动输送系统、装配机械、分拣或包装设备，实现精准运动控制。

3. 机器人控制系统

• 控制机器人关节或多轴运动，实现高精度路径规划和闭环控制。

4. 运动控制设备

• 用于测试平台、旋转装置或定位系统，提供精确的速度与位置控制。

5. 实验与检测系统

• 控制实验装置或测试平台的运动，实现重复性和高精度实验操作。

6. 装配与检测机械

• 用于工件定位、搬运或检测设备，确保动作精确、稳定。

英文资料：

GIDINGS&LEWIS DS2100 servo system drive module

Product Overview

DS2100 is a servo drive module in the Giddings&Lewis system, used to control the motion and position of servo motors. It receives control signals from the controller or CPU module, outputs high-precision current/voltage to the servo motor, and achieves fast response, precise positioning, and closed-loop motion control.

Product Features

High precision servo control

Support closed-loop control of position, speed, and torque to achieve high-precision motion control.

Quick Responsiveness

High speed processing of control signals to meet real-time control requirements for dynamic machining or automated production.

stable and reliable

Industrial grade design, high temperature resistance, vibration resistance, anti-interference, suitable for use in harsh environments.

Strong compatibility

It can seamlessly integrate with system modules such as Giddings&Lewis series CPUs, controllers, encoder modules, etc.

modular design

Plug in structure, easy to install, maintain, and expand the system.

Multi protection function

Built in overcurrent, overvoltage, and short-circuit protection ensures safe operation of the motor and drive module.

Programmable parameters

Support adjusting control parameters based on different motors and loads to achieve optimized performance.

Complete signal interface

Provide position feedback interface and analog/digital input/output interface for easy system integration.

Application field

Numerical Control Machine Tool (CNC)

Control the spindle or feed axis servo motor to achieve high-precision machining and automated operation.

Automatic production line

Drive conveyor systems, assembly machinery, sorting or packaging equipment to achieve precise motion control.

Robot control system

Control robot joints or multi axis movements to achieve high-precision path planning and closed-loop control.

Motion control equipment

Used for testing platforms, rotating devices, or positioning systems, providing precise speed and position control.

Experimental and Testing System

Control the movement of experimental devices or testing platforms to achieve repeatability and high-precision experimental operations.

Assembly and Testing Machinery

Used for workpiece positioning, handling, or inspection equipment to ensure precise and stable movements.
