GIDINGS&LEWIS 501-04537-01输入板 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 501-04537-01 输入板

产品概述

501-04537-01 输入板是 Giddings & Lewis 自动化与控制系统中的 输入接口模块，主要用于接收来自传感器、开关、按钮、检测器等现场设备的信号，并将其转换为系统控制器可识别的数据，以便 CPU 或控制器模块进行逻辑处理和控制决策。

产品特点

1. 多通道输入

• 支持多路输入信号接入，满足复杂系统的输入需求。

2. 信号隔离

• 内置电气隔离设计，有效防止现场干扰信号对系统核心部分的影响。

3. 高可靠性

• 工业级电路设计，抗干扰性能强，保证长期稳定运行。

4. 快速响应

• 能够快速采集输入信号并传输给控制单元，确保控制动作的实时性。

5. 兼容性强

• 可与 Giddings & Lewis 系统中的 CPU 板、通信模块、控制器模块无缝配合。

6. 模块化设计

• 插拔式结构，便于安装、更换与维护，减少停机时间。

7. 输入类型灵活

• 可支持数字量输入（如开关量）、部分型号可扩展模拟量输入能力。

8. 状态指示功能

• 带有输入状态指示灯，方便调试和现场监控。

英文资料：

GIDINGS&LEWIS 501-04537-01 Input Board

Product Overview

The 501-04537-01 input board is an input interface module in the Giddings&Lewis automation and control system, mainly used to receive signals from field devices such as sensors, switches, buttons, detectors, etc., and convert them into data recognizable by the system controller for logical processing and control decision-making by the CPU or controller module.

Product Features

Multi channel input

Support multiple input signal access to meet the input requirements of complex systems.

signal isolation

Built in electrical isolation design effectively prevents on-site interference signals from affecting the core parts of the system.

high reliability

Industrial grade circuit design, strong anti-interference performance, ensuring long-term stable operation.

quick response

Capable of quickly collecting input signals and transmitting them to the control unit, ensuring real-time control actions.

Strong compatibility

It can seamlessly integrate with the CPU board, communication module, and controller module in the Giddings&Lewis system.

modular design

Plug in structure, easy to install, replace and maintain, reducing downtime.

Flexible input types

Can support digital input (such as switch), and some models can expand analog input capability.

Status indication function

Equipped with input status indicator lights, convenient for debugging and on-site monitoring.

2.产      品      展      示
