GIDINGS&LEWIS  502-03420-01伺服接口模块 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 502-03420-01 伺服接口模块

一、产品概述

GIDDINGS&LEWIS 502-03420-01 是一款 伺服接口模块（Servo Interface Module），用于在控制系统与伺服驱动器之间实现信号传递和接口转换。该模块能够将 CPU 或控制器发出的指令信号转换为伺服驱动器可识别的控制信号，同时接收编码器反馈，实现闭环控制。广泛应用于数控机床、自动化生产线、机器人系统及其他高精度运动控制场景。

二、应用领域

1. 数控机床

• 控制主轴、进给轴和刀具位置，实现高速、高精度切削和加工操作。

• 支持多轴同步控制和复杂轨迹插补。

2. 自动化生产线

• 驱动伺服电机控制的输送带、装配机械手、分拣装置，实现生产节拍控制和工序自动化。

• 可协调多设备动作，提高生产效率和产品一致性。

3. 机器人系统

• 通过伺服接口控制机械臂关节或旋转平台，实现高精度位置和速度控制。

• 支持闭环反馈，保证重复定位精度和动作稳定性。

4. 印刷与包装设备

• 控制卷绕轴、送料装置及定位机构，实现精确对位和张力控制。

5. 检测与实验平台

• 在实验台、测试装置和高精密测量平台中，实现旋转或线性伺服运动的闭环控制。

6. 其他高精度工业应用

• 包括纺织机械、半导体制造设备、激光加工及自动化装配系统等。

英文资料：

GIDDINGS&LEWIS 502-03420-01 servo interface module

1、 Product Overview

GIDDINGS&LEWIS 502-03420-01 is a servo interface module used for signal transmission and interface conversion between control systems and servo drives. This module can convert the instruction signals issued by the CPU or controller into control signals that can be recognized by the servo drive, and receive feedback from the encoder to achieve closed-loop control. Widely used in CNC machine tools, automated production lines, robot systems, and other high-precision motion control scenarios.

2、 Application Fields

CNC machine tool

Control the spindle, feed axis, and tool position to achieve high-speed, high-precision cutting and machining operations.

Support multi axis synchronous control and complex trajectory interpolation.

Automatic production line

Drive servo motor controlled conveyor belts, assembly robotic arms, and sorting devices to achieve production cycle control and process automation.

Can coordinate the actions of multiple devices, improve production efficiency and product consistency.

robot system

Control the joints or rotating platform of the robotic arm through servo interfaces to achieve high-precision position and speed control.

Support closed-loop feedback to ensure repeat positioning accuracy and motion stability.

Printing and packaging equipment

Control the winding shaft, feeding device, and positioning mechanism to achieve precise alignment and tension control.

Testing and experimental platform

Realize closed-loop control of rotational or linear servo motion in experimental benches, testing devices, and high-precision measurement platforms.

Other high-precision industrial applications

Including textile machinery, semiconductor manufacturing equipment, laser processing, and automated assembly systems.

2.产      品      展      示
