GIDINGS&LEWIS  501-04026-00支持模块板 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 501-04026-00 支持模块板

一、产品概述

GIDDINGS&LEWIS 501-04026-00 是一款工业控制系统用 支持模块板（Support Module Board），用于为 CPU、I/O 模块及其他功能模块提供辅助电源、接口连接和信号分配功能。它在控制系统中起到桥梁和支撑作用，确保各模块稳定运行并实现信号正确传递。该模块板广泛应用于数控机床、自动化生产线和机器人系统。

二、技术参数（典型指标，实际以实物为准）

• 模块类型：支持模块板

• 功能：电源分配、信号连接、模块间通信辅助

• 接口类型：模块化插槽接口，兼容 GIDDINGS&LEWIS 系列 CPU 和 I/O 模块

• 输入电压：由系统机架提供 DC 5V / 24V

• 输出电压：稳定分配给连接模块

• 工作温度范围：0℃–60℃

• 抗干扰能力：工业级抗 EMI/EMC 设计

• 状态指示：LED 显示电源及模块运行状态

• 安装方式：插槽式模块化安装，便于快速维护和替换

三、应用场景

1. 数控机床

• 为 CPU、I/O 模块、驱动模块提供电源及接口连接，保证控制系统稳定运行。

2. 自动化生产线

• 支持生产线控制系统中各模块的信号分配与电源管理。

3. 机器人系统

• 为机械臂控制器、编码器接口及驱动模块提供稳定的辅助支持。

4. 检测与实验设备

• 为实验平台或测试设备的多模块控制系统提供信号和电源支撑。

5. 过程控制系统

• 在工业过程控制中为控制模块和接口模块提供稳定运行环境。

英文资料：

GIDDINGS&LEWIS 501-04026-00 supports module boards

1、 Product Overview

GIDINGS&LEWIS 501-04026-00 is a support module board for industrial control systems, used to provide auxiliary power, interface connections, and signal distribution functions for CPUs, I/O modules, and other functional modules. It serves as a bridge and support in the control system, ensuring stable operation of each module and achieving correct signal transmission. This module board is widely used in CNC machine tools, automated production lines, and robot systems.

2、 Technical parameters (typical indicators, actual subject to physical object)

Module type: Supports module boards

Function: Power distribution, signal connection, module communication assistance

Interface type: Modular slot interface, compatible with GIDDINGS&LEWIS series CPUs and I/O modules

Input voltage: DC 5V/24V provided by the system rack

Output voltage: stably distributed to the connection module

Working temperature range: 0 ℃ -60 ℃

Anti interference capability: Industrial grade anti EMI/EMC design

Status indication: LED displays the power and module operation status

Installation method: slot type modular installation, easy to maintain and replace quickly

3、 Application scenarios

CNC machine tool

Provide power and interface connections for CPU, I/O modules, and driver modules to ensure stable operation of the control system.

Automatic production line

Support signal distribution and power management for each module in the production line control system.

robot system

Provide stable auxiliary support for robotic arm controllers, encoder interfaces, and drive modules.

Testing and experimental equipment

Provide signal and power support for multi module control systems of experimental platforms or testing equipment.

process control system

Provide a stable operating environment for control modules and interface modules in industrial process control.
