GIDINGS&LEWIS 401-56451-50定位驱动器  PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 401-56451-50 定位驱动器

一、产品概述

GIDDINGS&LEWIS 401-56451-50 是一款工业级 定位驱动器，用于精确控制伺服或步进电机的位移和位置。该驱动器可接收 CPU 或控制器模块的指令，通过闭环或开环控制实现高速、高精度定位，广泛应用于数控机床、自动化生产线、机器人系统及其他需要精确运动控制的工业设备中。

二、技术参数（典型指标，实际以实物为准）

• 模块类型：定位驱动器

• 控制对象：伺服电机或步进电机

• 输入信号：数字控制指令、编码器反馈

• 输出信号：驱动电流/电压信号控制电机运动

• 定位精度：微米级（依电机与编码器精度）

• 响应速度：高速响应，适合动态定位和多轴同步

• 接口方式：模块化插槽设计，兼容 GIDDINGS&LEWIS 系列总线

• 工作电压：由系统机架提供 DC 24V / 48V（视配置）

• 工作环境：工业级温度、抗振动、抗电磁干扰

• 保护功能：过流、过压、短路和过热保护

• 状态指示：LED 显示电源、运行及故障状态

三、应用场景

1. 数控机床

• 精确控制刀具、工作台或进给轴的位置，实现高速高精度加工。

2. 自动化生产线

• 驱动输送机构、装配机械手或夹具，实现工序定位和节拍控制。

3. 机器人系统

• 控制机械臂关节或末端执行器，实现精确重复定位和轨迹控制。

4. 印刷与包装设备

• 控制卷绕、送料或对位机构，实现高精度定位和加工同步。

5. 检测与实验设备

• 实现实验台、测量装置或测试平台的精确位置控制。

英文资料：

GIDDINGS&LEWIS 401-56451-50 Positioning Drive

1、 Product Overview

GIDDINGS&LEWIS 401-56451-50 is an industrial grade positioning driver used for precise control of displacement and position of servo or stepper motors. This driver can receive instructions from CPU or controller modules and achieve high-speed and high-precision positioning through closed-loop or open-loop control. It is widely used in CNC machine tools, automated production lines, robot systems, and other industrial equipment that require precise motion control.

2、 Technical parameters (typical indicators, actual subject to physical object)

Module type: Positioning driver

Control object: servo motor or stepper motor

Input signals: digital control commands, encoder feedback

Output signal: Drive current/voltage signal to control motor motion

Positioning accuracy: micrometer level (depending on motor and encoder accuracy)

Response speed: High speed response, suitable for dynamic positioning and multi axis synchronization

Interface method: Modular slot design, compatible with GIDDINGS&LEWIS series buses

Working voltage: DC 24V/48V provided by the system rack (depending on configuration)

Working environment: industrial grade temperature, anti vibration, anti electromagnetic interference

Protection function: overcurrent, overvoltage, short circuit, and overheating protection

Status indication: LED displays power, operation, and fault status

3、 Application scenarios

CNC machine tool

Accurately control the position of the tool, worktable, or feed axis to achieve high-speed and high-precision machining.

Automatic production line

Drive the conveying mechanism, assemble the robotic arm or fixture to achieve process positioning and beat control.

robot system

Control the joints or end effectors of the robotic arm to achieve precise repetitive positioning and trajectory control.

Printing and packaging equipment

Control the winding, feeding or alignment mechanism to achieve high-precision positioning and synchronous processing.

Testing and experimental equipment

Realize precise position control of experimental benches, measuring devices, or testing platforms.
