GIDINGS&LEWIS 401-30234-01步进电机PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 401-30234-01 步进电机

一、产品概述

GIDDINGS&LEWIS 401-30234-01 是一款工业级 步进电机，用于精确的角度和位移控制。该电机无需闭环反馈即可实现高精度定位，常与步进驱动器配合使用，广泛应用于数控机床、自动化生产线、机器人系统以及其他高精度位置控制场景。步进电机结构简单、可靠性高，适合重复定位和慢速高精度控制。

二、技术参数（典型指标，实际以实物为准）

• 电机类型：两相或三相步进电机

• 额定电压：DC 24V–48V（依配置）

• 步距角：1.8° 或 0.9°（可定制）

• 额定电流：1–5A（依据型号）

• 保持扭矩：0.5–3 N·m（根据规格）

• 惯量：低惯量设计，适合快速启动/停止

• 安装方式：法兰安装，标准机架接口

• 工作环境：工业级温度、抗振动、抗干扰

• 冷却方式：自然风冷或风扇辅助

英文资料：

GIDDINGS&LEWIS 401-30234-01 Stepper Motor

1、 Product Overview

GIDINGS&LEWIS 401-30234-01 is an industrial grade stepper motor used for precise angle and displacement control. This motor can achieve high-precision positioning without closed-loop feedback and is often used in conjunction with stepper drivers. It is widely used in CNC machine tools, automated production lines, robot systems, and other high-precision position control scenarios. The stepper motor has a simple structure and high reliability, suitable for repeated positioning and slow high-precision control.

2、 Technical parameters (typical indicators, actual subject to physical object)

Motor type: Two phase or three-phase stepper motor

Rated voltage: DC 24V -48V (depending on configuration)

Step angle: 1.8 ° or 0.9 ° (customizable)

Rated current: 1-5A (depending on model)

Maintain torque: 0.5-3 N · m (according to specifications)

Inertia: Low inertia design, suitable for quick start/stop

Installation method: flange installation, standard rack interface

Working environment: industrial grade temperature, anti vibration, anti-interference

Cooling method: natural air cooling or fan assisted

2.产      品      展      示
