GIDDINGS&LEWIS 572-03553-01 直流输入板

一、产品概述

GIDDINGS&LEWIS 572-03553-01 是一款工业控制系统用 直流输入模块，用于采集来自传感器、开关和其他直流信号源的数字量信号，并将其转换为控制系统可识别的数据。该模块提供高可靠性信号处理和抗干扰能力，是数控机床、自动化生产线和机器人系统中关键的输入接口单元。

二、技术参数（典型指标，具体以实物为准）

• 模块类型：直流输入板

• 输入电压范围：DC 5–30V

• 通道数量：多通道输入（典型 8–16 路）

• 输入类型：数字量直流信号（ON/OFF）

• 响应时间：典型 1–5 ms

• 隔离方式：光电隔离，增强抗干扰能力

• 接口方式：模块化插槽设计，兼容 GIDDINGS&LEWIS 系统总线

• 工作电压：由系统机架提供 DC 5V/24V

• 工作环境：工业级温度、抗振动与抗电磁干扰设计

• 状态指示：LED 显示各通道信号状态

三、应用场景

1. 数控机床

• 采集限位开关、急停开关、刀具检测等数字信号，实现安全保护和状态反馈。

2. 自动化生产线

• 监控传感器、光电开关、按钮等直流数字信号，实现工序控制和故障检测。

3. 机器人系统

• 采集末端执行器或传感器状态，为闭环控制和动作逻辑提供反馈。

4. 过程控制系统

• 采集工业设备状态信号，确保系统逻辑控制的准确性与安全性。

5. 检测与实验平台

• 实时采集实验或测试过程中各种开关量信号，实现精确监控。

英文资料：

GIDINGS&LEWIS 572-03553-01 DC Input Board

1、 Product Overview

GIDINGS&LEWIS 572-03553-01 is a DC input module for industrial control systems, used to collect digital signals from sensors, switches, and other DC signal sources, and convert them into data recognizable by the control system. This module provides high reliability signal processing and anti-interference capabilities, and is a key input interface unit in CNC machine tools, automated production lines, and robot systems.

2、 Technical parameters (typical indicators, specific subject to physical object)

Module type: DC input board

Input voltage range: DC 5-30V

Number of channels: Multi channel input (typical 8-16 channels)

Input type: Digital DC signal (ON/OFF)

Response time: Typical 1-5 ms

Isolation method: photoelectric isolation, enhancing anti-interference ability

Interface method: Modular slot design, compatible with GIDDINGS&LEWIS system bus

Working voltage: DC 5V/24V provided by the system rack

Work environment: Industrial grade temperature, anti vibration and anti electromagnetic interference design

Status indication: LED displays the signal status of each channel

3、 Application scenarios

CNC machine tool

Collect digital signals such as limit switches, emergency stop switches, and tool detection to achieve safety protection and status feedback.

Automatic production line

Monitor DC digital signals such as sensors, photoelectric switches, buttons, etc. to achieve process control and fault detection.

robot system

Collect the status of end effectors or sensors to provide feedback for closed-loop control and action logic.

process control system

Collect status signals of industrial equipment to ensure the accuracy and safety of system logic control.

Testing and experimental platform

Real time collection of various switch signals during experiments or testing processes to achieve precise monitoring.

2.产      品      展      示
