GIDINGS&LEWIS 502-03786-00输入编码器 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 502-03786-00 输入编码器模块

一、产品概述

GIDDINGS&LEWIS 502-03786-00 输入编码器模块是一款工业控制系统用 位置/速度反馈输入模块，用于读取旋转或线性编码器的信号，并将其转换为控制系统可识别的数据。该模块为机床、自动化生产线和机器人系统提供精确的运动反馈，支持闭环控制和高精度定位，是实现多轴同步控制和高速运动控制的重要组件。

二、技术参数（典型指标，具体以实物为准）

• 模块类型：编码器输入模块

• 通道数量：多通道输入（典型 4–8 路）

• 支持编码器类型：增量式编码器、绝对值编码器

• 输入信号电平：TTL / HTL（依据编码器类型）

• 分辨率：取决于编码器本体，可高达 25,000–50,000 PPR

• 采样速度：高速采样，可满足实时控制要求

• 隔离方式：光电隔离，增强抗干扰能力

• 接口方式：模块化插槽设计，兼容 GIDDINGS&LEWIS 502 系列控制总线

• 状态指示：LED 显示通道状态与错误信号

三、应用场景

1. 数控机床

• 接收主轴、进给轴的编码器信号，实现高精度闭环运动控制。

2. 自动化生产线

• 对输送带、机械手臂或装配机构的运动位置进行实时反馈。

3. 机器人系统

• 获取关节角度和位置数据，确保多关节运动协调与重复定位精度。

4. 印刷与包装机械

• 精确采集卷绕、张力和对位过程中的速度与位置信息。

5. 测试与检测平台

• 为精密运动平台或实验装置提供高速、精确的位置反馈信号

英文资料：

GIDDINGS&LEWIS 502-03786-00 Input Encoder Module

1、 Product Overview

GIDDINGS&LEWIS 502-03786-00 Input Encoder Module is a position/velocity feedback input module for industrial control systems, used to read signals from rotary or linear encoders and convert them into data recognizable by the control system. This module provides precise motion feedback for machine tools, automated production lines, and robot systems, supports closed-loop control and high-precision positioning, and is an important component for achieving multi axis synchronous control and high-speed motion control.

2、 Technical parameters (typical indicators, specific subject to physical object)

Module type: Encoder input module

Number of channels: Multi channel input (typical 4-8 channels)

Supporting encoder types: incremental encoder, absolute value encoder

Input signal level: TTL/HTL (depending on encoder type)

Resolution: Depending on the encoder body, it can reach up to 25000-50000 PPR

Sampling speed: High speed sampling to meet real-time control requirements

Isolation method: photoelectric isolation, enhancing anti-interference ability

Interface method: Modular slot design, compatible with GIDDINGS&LEWIS 502 series control bus

Status indication: LED displays channel status and error signals

3、 Application scenarios

CNC machine tool

Receive encoder signals from the spindle and feed axis to achieve high-precision closed-loop motion control.

Automatic production line

Real time feedback on the movement position of conveyor belts, robotic arms, or assembly mechanisms.

robot system

Obtain joint angle and position data to ensure multi joint motion coordination and repeat positioning accuracy.

Printing and packaging machinery

Accurately collect speed and position information during winding, tension, and alignment processes.

Testing and Inspection Platform

Provide high-speed and accurate position feedback signals for precision motion platforms or experimental devices

2.产      品      展      示
