GIDINGS&LEWIS  501-02989-00存储板 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 501-02989-00 存储板

一、产品概述

GIDDINGS&LEWIS 501-02989-00 存储板是一款工业控制系统用 非易失性存储模块，用于存储控制程序、参数数据和系统配置。它通常与 CPU 模块、运动控制器和 I/O 模块配合使用，为机床、自动化生产线和机器人系统提供可靠的数据保存与快速访问功能。该存储板具备抗干扰能力强、数据可靠性高的特点。

二、技术参数（典型指标，具体以实物为准）

• 模块类型：非易失性存储板

• 存储类型：EEPROM / Flash

• 容量：典型 128KB–1MB（视型号配置）

• 接口方式：模块化插槽，兼容 GIDDINGS&LEWIS 系统总线

• 数据保持时间：≥10 年（常温条件下）

• 读写次数：≥100,000 次

• 工作电压：由系统机架提供电源

• 工作环境：工业级温度和抗振动设计，适合机床及自动化设备环境

• 状态指示：LED 或系统监控状态反馈

三、应用场景

1. 数控机床

• 存储机床控制程序、工件加工参数和运动轨迹数据。

2. 自动化生产线

• 保存生产线配置参数、工艺数据和设备状态信息。

3. 机器人系统

• 存储控制程序、关节坐标和动作序列数据。

4. 检测与实验设备

• 保存实验参数、测试数据及历史记录，保证数据可靠性。

5. 过程控制系统

• 存储关键控制参数，实现系统断电后快速恢复运行。

英文资料：

GIDDINGS&LEWIS 501-02989-00 Storage Board

1、 Product Overview

GIDDINGS&LEWIS 501-02989-00 storage board is a non-volatile storage module for industrial control systems, used to store control programs, parameter data, and system configurations. It is usually used in conjunction with CPU modules, motion controllers, and I/O modules to provide reliable data storage and fast access functions for machine tools, automated production lines, and robot systems. This storage board has the characteristics of strong anti-interference ability and high data reliability.

2、 Technical parameters (typical indicators, specific subject to physical object)

Module type: non-volatile storage board

Storage type: EEPROM/Flash

Capacity: Typical 128KB – 1MB (depending on model configuration)

Interface method: Modular slot, compatible with GIDDINGS&LEWIS system bus

Data retention time: ≥ 10 years (under normal temperature conditions)

Read and write frequency: ≥ 100000 times

Working voltage: Powered by the system rack

Working environment: Industrial grade temperature and anti vibration design, suitable for machine tools and automation equipment environments

Status indication: LED or system monitoring status feedback

3、 Application scenarios

CNC machine tool

Store machine control programs, workpiece processing parameters, and motion trajectory data.

Automatic production line

Save production line configuration parameters, process data, and equipment status information.

robot system

Store control programs, joint coordinates, and action sequence data.

Testing and experimental equipment

Save experimental parameters, test data, and historical records to ensure data reliability.

process control system

Store key control parameters to achieve rapid recovery of system operation after power failure.

2.产      品      展      示
