GIDINGS&LEWIS  401-34401-00伺服驱动器  PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 401-34401-00 伺服驱动器

一、产品概述

GIDDINGS&LEWIS 401-34401-00 是一款工业级 交流伺服驱动器，用于为伺服电机提供高性能的电流、速度和位置控制。该驱动器广泛应用于数控机床、自动化产线、机器人和过程控制系统中，具有动态响应快、控制精度高、运行可靠性强的特点。它支持多种控制模式和反馈方式，能够满足复杂的工业运动控制需求。

二、技术参数（典型指标，具体以实物为准）

• 输入电源：三相 AC 200–240V 或 380–480V（依据配置）

• 输出功率范围：适配不同功率等级的伺服电机（几百 W 至数 kW）

• 控制模式：

• 位置控制

• 速度控制

• 扭矩控制

• 矢量控制 / 闭环伺服控制

• 反馈接口：支持增量式编码器、旋转变压器反馈

• 通信接口：RS-232/RS-485，可扩展工业现场总线

• 保护功能：过压、欠压、过流、过热、短路保护

• 冷却方式：风冷

• 安装方式：机柜内模块化安装

三、应用场景

1. 数控机床

• 驱动主轴或进给伺服，实现高精度切削和复杂轨迹加工。

2. 自动化生产线

• 控制输送、装配、分拣等设备，保证动作同步与节拍稳定。

3. 机器人系统

• 提供高速伺服驱动，支持多关节协调运动和重复定位。

4. 包装与印刷机械

• 在高速分切、定位、张力控制环节中提供精确的运动控制。

5. 检测与实验设备

• 为测试工装和运动台提供稳定驱动，满足实验室或工业检测需求。

英文资料：

GIDDINGS&LEWIS 401-34401-00 servo drive

1、 Product Overview

GIDINGS&LEWIS 401-34401-00 is an industrial grade AC servo drive used to provide high-performance current, speed, and position control for servo motors. This driver is widely used in CNC machine tools, automated production lines, robots, and process control systems, and has the characteristics of fast dynamic response, high control accuracy, and strong operational reliability. It supports multiple control modes and feedback methods, which can meet complex industrial motion control requirements.

2、 Technical parameters (typical indicators, specific subject to physical object)

Input power supply: three-phase AC 200-240V or 380-480V (depending on configuration)

Output power range: Suitable for servo motors of different power levels (several hundred W to several kW)

Control mode:

position control

speed control

torque control

Vector control/closed-loop servo control

Feedback interface: Supports incremental encoder and rotary transformer feedback

Communication interface: RS-232/RS-485, expandable industrial fieldbus

Protection function: overvoltage, undervoltage, overcurrent, overheating, short circuit protection

Cooling method: air cooling

Installation method: Modular installation inside the cabinet

3、 Application scenarios

CNC machine tool

Drive the spindle or feed servo to achieve high-precision cutting and complex trajectory machining.

Automatic production line

Control conveying, assembly, sorting and other equipment to ensure synchronized movements and stable rhythm.

robot system

Provide high-speed servo drive, support multi joint coordinated motion and repetitive positioning.

Packaging and Printing Machinery

Provide precise motion control in high-speed cutting, positioning, and tension control processes.

Testing and experimental equipment

Provide stable driving for testing fixtures and motion tables to meet laboratory or industrial testing needs.

2.产      品      展      示
