GIDINGS&LEWIS  502-03674-00直流水槽输出模块  PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 502-03674-00 直流水槽输出模块

一、产概述

GIDDINGS&LEWIS 502-03674-00 直流水槽输出模块是一款用于工业自动化控制系统的 直流输出接口单元。该模块主要负责将CPU或控制器输出的逻辑信号转换为可驱动外部负载的直流输出信号，用于控制继电器、接触器、指示灯、执行器等设备。其采用直流水槽（DC Sink/Source）方式输出，能够适配不同类型的工业负载，具有响应速度快、隔离性强、可靠性高等特点。

二、技术参数（典型指标，实际以实物为准）

• 模块类型：数字量直流输出模块

• 通道数量：8/16 路（依据配置）

• 输出方式：直流水槽（Sink）/ 源极（Source）输出

• 电压等级：DC 24V（典型），部分型号支持 DC 12–48V

• 输出电流：单通道 0.5A – 2A

• 隔离方式：光耦隔离，提升信号抗干扰能力

• 响应时间：≤1ms，满足高速开关需求

• 接口方式：模块化插槽设计，兼容 GIDDINGS&LEWIS 控制系统总线

• 保护功能：过流保护、短路保护

三、应用场景

1. 数控机床控制

• 控制冷却泵、润滑系统、报警灯等外部直流负载。

2. 自动化生产线

• 用于驱动执行机构（电磁阀、直流马达），实现工序动作控制。

3. 机器人系统

• 控制末端执行器、夹具和信号指示装置。

4. 包装与印刷机械

• 精确控制输送、分拣与定位单元中的直流负载。

5. 检测与测试设备

• 输出控制信号，驱动测试夹具、信号灯、执行部件。

英文资料：

GIDINGS&LEWIS 502-03674-00 DC Water Tank Output Module

1、 Product Overview

GIDINGS&LEWIS 502-03674-00 DC Water Tank Output Module is a DC output interface unit used in industrial automation control systems. This module is mainly responsible for converting the logic signals output by the CPU or controller into DC output signals that can drive external loads, which are used to control devices such as relays, contactors, indicator lights, and actuators. It adopts a DC Sink/Source output method, which can adapt to different types of industrial loads and has the characteristics of fast response speed, strong isolation, and high reliability.

2、 Technical parameters (typical indicators, actual subject to physical object)

Module type: Digital DC output module

Number of channels: 8/16 channels (depending on configuration)

Output mode: DC sink/source output

Voltage level: DC 24V (typical), some models support DC 12-48V

Output current: Single channel 0.5A-2A

Isolation method: Optocoupler isolation to enhance signal anti-interference ability

Response time: ≤ 1ms, meets high-speed switch requirements

Interface method: Modular slot design, compatible with GIDDINGS&LEWIS control system bus

Protection functions: overcurrent protection, short circuit protection

3、 Application scenarios

Numerical Control Machine Tool Control

Control external DC loads such as cooling pumps, lubrication systems, alarm lights, etc.

Automatic production line

Used to drive actuators (solenoid valves, DC motors) and achieve process action control.

robot system

Control end effectors, fixtures, and signal indicating devices.

Packaging and Printing Machinery

Accurately control the DC load in the conveying, sorting, and positioning units.

Testing and Inspection Equipment

Output control signals to drive test fixtures, signal lights, and execution components.

2.产      品      展      示
