GIDINGS&LEWIS  502-03679-02编码器模块 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS&LEWIS 502-03679-02 编码器模块

一、产品概述

GIDDINGS&LEWIS 502-03679-02 编码器模块是一款用于运动控制和位置检测的输入模块，主要功能是接收来自旋转或直线编码器的脉冲信号，并将其转换为控制系统可识别的数字量数据。它常用于数控机床、自动化生产线和机器人系统中，用于实现速度监控、位置反馈和闭环控制。

二、技术参数（典型指标，具体以实际为准）

• 模块类型：编码器输入模块

• 信号支持：增量式编码器（A/B/Z通道）、部分型号可支持正交信号

• 输入电压：5V/12V/24V TTL 或差分信号

• 分辨率：根据外部编码器精度而定，可支持高达几千至上百万脉冲/转

• 通道数：多通道输入，支持双编码器信号接入

• 响应频率：高频输入，典型可达200kHz–1MHz

• 隔离方式：通道与控制总线电气隔离

• 接口方式：模块化插槽，兼容GIDDINGS&LEWIS 系统总线

• 功能特性：

• 位置捕获与计数

• 速度与方向判定

• 零点复位/参考点检测

• 支持实时闭环控制

三、应用场景

1. 数控机床

• 提供主轴和工作台位置反馈，实现高精度插补与运动控制。

2. 机器人系统

• 用于关节位置检测与速度反馈，提升轨迹控制精度。

3. 自动化生产线

• 在传送带、装配机械中用于速度同步与物料定位。

4. 印刷与纺织机械

• 实现张力控制与对位精度控制。

5. 检测与测试设备

• 提供运动部件的高精度位置反馈，确保实验或生产工艺精度。

英文资料：

GIDDINGS&LEWIS 502-03679-02 Encoder Module

1、 Product Overview

The GIDINGS&LEWIS 502-03679-02 encoder module is an input module used for motion control and position detection. Its main function is to receive pulse signals from rotary or linear encoders and convert them into digital data that can be recognized by the control system. It is commonly used in CNC machine tools, automated production lines, and robot systems to achieve speed monitoring, position feedback, and closed-loop control.

2、 Technical parameters (typical indicators, subject to actual conditions)

Module type: Encoder input module

Signal support: Incremental encoders (A/B/Z channels), some models can support orthogonal signals

Input voltage: 5V/12V/24V TTL or differential signal

Resolution: Depending on the accuracy of the external encoder, it can support up to several thousand to millions of pulses per revolution

Number of channels: Multi channel input, supporting dual encoder signal access

Response frequency: High frequency input, typically up to 200kHz-1MHz

Isolation method: Channel and control bus are electrically isolated

Interface method: Modular slot, compatible with GIDDINGS&LEWIS system bus

Features

Position capture and counting

Speed and direction determination

Zero point reset/reference point detection

Support real-time closed-loop control

3、 Application scenarios

CNC machine tool

Provide spindle and worktable position feedback to achieve high-precision interpolation and motion control.

robot system

Used for joint position detection and velocity feedback to improve trajectory control accuracy.

Automatic production line

Used for speed synchronization and material positioning in conveyor belts and assembly machinery.

Printing and Textile Machinery

Realize tension control and alignment accuracy control.

Testing and Inspection Equipment

Provide high-precision position feedback for moving parts to ensure experimental or production process accuracy.

2.产      品      展      示
