GIDINGS&LEWIS  503-25909-00输入模拟模块 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 503-25909-00 输入模拟模块

产品概述

GIDDINGS & LEWIS 503-25909-00 输入模拟模块是一款工业级信号采集设备，主要用于数控机床和自动化控制系统中，将外部模拟信号（如电压、电流）转换为控制器可处理的数字信号。该模块具备高精度、高稳定性和抗干扰能力，适用于复杂工业环境下的实时监控与控制。

技术参数（典型特性，具体以实际型号为准）

• 输入类型：模拟电压或电流信号

• 通道数量：多通道输入，支持同时采集多个信号

• 转换精度：高分辨率 A/D 转换，保证精确测量

• 响应速度：快速采样，满足实时控制需求

• 电气隔离：输入通道与控制器隔离，增强抗干扰能力

• 接口方式：标准工业接口，兼容 G&L 控制器和 PLC 系统

• 安装方式：模块化设计，便于机架安装与扩展

产品应用领域

1. 数控机床

• 用于采集主轴、进给轴及刀具的模拟信号。

• 提供精确的速度、电流或温度反馈，保证加工精度。

2. 自动化生产线

• 采集传感器、流量计、压力传感器等设备的模拟信号。

• 实现生产工序的实时监控与反馈控制。

3. 过程控制系统

• 化工、冶金、造纸等连续生产过程的参数采集。

• 实现阀门、电机、泵等设备的闭环控制。

4. 机器人系统

• 获取力传感器、位置传感器或其他模拟量输入。

• 支持高精度、多轴同步运动控制。

5. 测试与实验平台

• 用于实验设备或检测装置的模拟信号采集。

• 提供高速、高精度的测量能力，满足科研和质量检测需求。

英文资料：

GIDINGS&LEWIS 503-25909-00 Input Analog Module

Product Overview

GIDINGS&LEWIS 503-25909-00 Input Analog Module is an industrial grade signal acquisition device mainly used in CNC machine tools and automation control systems to convert external analog signals (such as voltage and current) into digital signals that can be processed by the controller. This module has high precision, high stability, and anti-interference ability, suitable for real-time monitoring and control in complex industrial environments.

Technical parameters (typical characteristics, specific subject to actual model)

Input type: Analog voltage or current signal

Number of channels: Multi channel input, supporting simultaneous acquisition of multiple signals

Conversion accuracy: High resolution A/D conversion ensures accurate measurement

Response speed: Fast sampling to meet real-time control requirements

Electrical isolation: isolate the input channel from the controller to enhance anti-interference capability

Interface method: Standard industrial interface, compatible with G&L controllers and PLC systems

Installation method: Modular design for easy rack installation and expansion

Product application areas

CNC machine tool

Used to collect analog signals of spindle, feed axis, and cutting tools.

Provide precise feedback on speed, current, or temperature to ensure machining accuracy.

Automatic production line

Collect analog signals from sensors, flow meters, pressure sensors, and other devices.

Realize real-time monitoring and feedback control of production processes.

process control system

Parameter collection for continuous production processes such as chemical engineering, metallurgy, and papermaking.

Realize closed-loop control of equipment such as valves, motors, pumps, etc.

robot system

Obtain force sensors, position sensors, or other analog inputs.

Support high-precision, multi axis synchronous motion control.

Testing and experimental platform

Used for analog signal acquisition in experimental equipment or detection devices.

Provide high-speed and high-precision measurement capabilities to meet the needs of scientific research and quality inspection.
