GIDINGS&LEWIS 502-03840-04伺服编码器 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 502-03840-04 伺服编码器

产品特点

1. 高分辨率反馈

• 提供精确的位置和速度反馈，满足数控机床和伺服系统的高精度控制需求。

2. 实时响应快

• 编码器信号延迟极低，可实现高速伺服环路控制，保证动作的平稳与同步。

3. 结构紧凑

• 模块化设计，体积小巧，便于集成在伺服驱动器或电机系统中。

4. 抗干扰能力强

• 具备良好的电磁兼容性和电气隔离设计，在复杂工业环境下保持稳定信号传输。

5. 多种输出方式

• 支持差分信号、正交脉冲等多种输出形式，适配不同的控制系统。

6. 高可靠性

• 工业级设计，具备防尘、防振、耐温等特性，可长期稳定运行。

7. 兼容性好

• 与 GIDDINGS & LEWIS 系列伺服驱动器及控制系统无缝配合，也可应用于其他标准控制平台。

英文资料：

GIDINGS&LEWIS 502-03840-04 servo encoder

Product Features

High resolution feedback

Provide precise position and velocity feedback to meet the high-precision control requirements of CNC machine tools and servo systems.

Fast real-time response

The encoder signal delay is extremely low, which can achieve high-speed servo loop control, ensuring smooth and synchronized action.

compact structure

Modular design, compact size, easy to integrate into servo drives or motor systems.

Strong anti-interference ability

Having good electromagnetic compatibility and electrical isolation design, maintaining stable signal transmission in complex industrial environments.

Multiple output modes

Support multiple output forms such as differential signals and orthogonal pulses, and adapt to different control systems.

high reliability

Industrial grade design, with features such as dust prevention, vibration resistance, and temperature resistance, capable of long-term stable operation.

Good compatibility

Seamlessly compatible with GIDINGS&LEWIS series servo drives and control systems, it can also be applied to other standard control platforms.

2.产      品      展      示
