1. You may enter command names in either uppercase or lowercase
characters.
2. Some diagnostics depend on restart defaults that are set up only in a
particular restart mode. Refer to the documentation on a particular
diagnostic for the correct mode. Test Sets marked with an asterisk
(*) are not available on PPCBug Release 3.1 and earlier.Overview
You can use the factory-installed debug monitor, PPCBug, to modify
certain parameters contained in the PowerPC board’s Non-Volatile RAM
(NVRAM), also known as Battery Backed-up RAM (BBRAM).
❏ The Board Information Block in NVRAM contains various
elements relating to the operating parameters of the hardware itself.
Use the PPCBug command CNFG to change those parameters.
❏ Use the PPCBug command ENV to change configurable PPCBug
parameters in NVRAM.
The CNFG and ENV commands are both described in the PPCBug
Firmware Package User’s Manual, listed in Appendix D, Related
Documentation. Refer to that manual for general information about their
use and capabilities.
The following paragraphs present additional information about CNFG and
ENV that is specific to the debugger, along with the PPCBug parameters
that can be configured with the ENV command.CNFG – Configure Board Information Block
Use this command to display and configure the Board Information Block,
which is resident within the NVRAM. The Board Information Block
contains various elements that correspond to specific operational
parameters of the PowerPC board. The board structure for the MVME2700
is as shown in the following example:The parameters that are quoted are left-justified character (ASCII) strings
padded with space characters, and the quotes (“) are displayed to indicate
the size of the string. Parameters that are not quoted are considered data
strings, and data strings are right-justified. The data strings are padded
with zeroes if the length is not met.
The Board Information Block is factory-configured before shipment.
There is no need to modify block parameters unless the NVRAM is
corrupted.
Refer to the MVME2600/2700 Series Single Board Computer
Programmer’s Reference Guide (applicable to the MVME2700) for the
actual location and other information about the Board Information Block.
Refer to the PPCBug Firmware Package User’s Manual for a description
of CNFG and examples.ENV – Set Environment
Use the ENV command to view and/or configure interactively all PPCBug
operational parameters that are kept in Non-Volatile RAM (NVRAM).
Refer to the PPCBug Firmware Package User’s Manual for a description
of the use of ENV. Additional information on registers in the Universe II
ASIC that affect these parameters can be found in the Programmer’s
Reference Guide for your PowerPC board.
Listed and described below are the parameters that you can configure
using ENV. The default values shown are those in effect when this
publication went to print.
