GIDINGS&LEWIS  M.1301.9806热电偶 PDF资料

1.产 品 资 料 介 绍：

产品概述

Giddings & Lewis M.1301.9806 是 PiC 系列控制系统中的热电偶输入模块，用于采集工业过程中的温度信号。它将热电偶传感器输出的微弱电压信号转换为可供控制器处理的标准信号，实现温度监测和控制，是高精度加工设备及工业自动化系统的重要组件。

产品特点

1. 高精度温度采集

• 支持多种类型热电偶（如 K、J、T 型），满足不同工业测温需求。

• 内置冷端补偿功能，保证温度测量精度。

2. 多通道输入

• 可同时处理多路热电偶信号，实现多点温度监控。

• 支持模块化扩展，满足复杂系统需求。

3. 信号隔离与保护

• 输入与控制器之间电气隔离，提高抗干扰能力。

• 防过流、防短路设计，保障模块及控制系统安全。

4. 工业环境适应性

• 抗振动、抗冲击设计，适合机床和自动化生产环境。

• EMC 抗干扰能力强，保证长期稳定运行。

5. 状态指示与维护便利

• LED 指示模块运行状态，便于现场监控。

• 模块化设计，方便安装、调试及更换。

应用领域

• 数控机床：监控加工区域或主轴温度，防止过热影响加工精度。

• 工业自动化生产线：采集关键设备温度，实现自动温控和保护。

• 过程控制系统：对炉温、液体或气体温度进行实时监测和控制。

• 实验与测试设备：用于温度数据采集、分析和过程控制实验。

• 设备安全与维护：通过温度监控实现过热报警和故障保护。

英文资料：

Product Overview

Giddings&Lewis M.1301.9806 is a thermocouple input module in the PiC series control system, used to collect temperature signals in industrial processes. It converts the weak voltage signal output by the thermocouple sensor into a standard signal that can be processed by the controller, achieving temperature monitoring and control. It is an important component of high-precision processing equipment and industrial automation systems.

Product Features

High precision temperature acquisition

Support multiple types of thermocouples (such as K, J, T type) to meet different industrial temperature measurement needs.

Built in cold end compensation function ensures temperature measurement accuracy.

Multi channel input

It can simultaneously process multiple thermocouple signals to achieve multi-point temperature monitoring.

Support modular expansion to meet complex system requirements.

Signal isolation and protection

Electrical isolation between input and controller enhances anti-interference capability.

Anti overcurrent and anti short circuit design ensures the safety of modules and control systems.

Industrial environment adaptability

Anti vibration and anti impact design, suitable for machine tools and automated production environments.

EMC has strong anti-interference ability, ensuring long-term stable operation.

Status indication and convenient maintenance

LED indicates the operating status of the module for easy on-site monitoring.

Modular design, convenient for installation, debugging, and replacement.

Application field

Numerical Control Machine Tool: Monitor the temperature of the machining area or spindle to prevent overheating from affecting machining accuracy.

Industrial automation production line: Collect the temperature of key equipment to achieve automatic temperature control and protection.

Process control system: Real time monitoring and control of furnace temperature, liquid or gas temperature.

Experimental and testing equipment: used for temperature data collection, analysis, and process control experiments.

Equipment safety and maintenance: achieve overheating alarm and fault protection through temperature monitoring.
