GIDINGS&LEWIS 503-17600-00涡轮处理器 PDF资料

1.产 品 资 料 介 绍：

产品概述

Giddings & Lewis 503-17600-00 涡轮处理器是专为高速旋转机械和数控系统设计的处理模块，用于采集涡轮或旋转设备的速度、位置及加速度信号，并进行实时处理和反馈控制。该模块可实现高精度运动控制和机械同步，是精密机床和自动化系统的重要组成部分。

产品特点

1. 高速信号处理能力

• 可实时采集和处理涡轮或旋转设备的高速信号。

• 支持多轴运动数据同步运算，保证系统高响应性。

2. 高精度控制

• 结合闭环反馈，实现精确速度、位置和加速度控制。

• 支持高速切削和动态负载下的稳定操作。

3. 接口与兼容性

• 提供标准化接口，可与 PiC 系列控制器及伺服模块连接。

• 支持编码器及传感器信号输入，实现系统扩展和多设备集成。

4. 工业环境适应性

• 工业级设计，抗振动、抗冲击，适应机床及自动化生产环境。

• EMC 抗干扰能力强，保证长期可靠运行。

5. 状态监控与诊断功能

• 内置状态指示灯显示模块运行情况，便于维护。

• 支持故障报警和诊断，减少停机时间。

应用领域

• 数控机床：采集主轴或进给轴的高速旋转信号，实现精确闭环控制。

• 多轴自动化系统：支持多轴联动控制和复杂运动路径规划。

• 涡轮机械与旋转设备：实时监测转速、位置及加速度，实现安全和高效运行。

• 工业自动化生产线：驱动高动态执行设备，实现精确定位和同步动作。

• 实验与测试设备：用于高速旋转机械的数据采集、测试和性能分析。

英文资料：

Product Overview

Giddings&Lewis 503-17600-00 Turbine Processor is a processing module designed specifically for high-speed rotating machinery and CNC systems. It is used to collect speed, position, and acceleration signals of turbines or rotating equipment, and perform real-time processing and feedback control. This module can achieve high-precision motion control and mechanical synchronization, and is an important component of precision machine tools and automation systems.

Product Features

High speed signal processing capability

Real time collection and processing of high-speed signals from turbines or rotating equipment.

Support multi axis motion data synchronization operation to ensure high system responsiveness.

high-precision control

Combining closed-loop feedback to achieve precise speed, position, and acceleration control.

Support stable operation under high-speed cutting and dynamic loads.

Interface and compatibility

Provide standardized interfaces that can be connected to PiC series controllers and servo modules.

Support encoder and sensor signal input, achieve system expansion and multi device integration.

Industrial environment adaptability

Industrial grade design, resistant to vibration and impact, suitable for machine tools and automated production environments.

EMC has strong anti-interference ability, ensuring long-term reliable operation.

Status monitoring and diagnostic function

The built-in status indicator light displays the operation status of the module, making it easy to maintain.

Support fault alarm and diagnosis to reduce downtime.

Application field

Numerical Control Machine Tool: Collecting high-speed rotation signals of the spindle or feed axis to achieve precise closed-loop control.

Multi axis automation system: supports multi axis linkage control and complex motion path planning.

Turbomachinery and rotating equipment: Real time monitoring of speed, position, and acceleration to achieve safe and efficient operation.

Industrial automation production line: drives high dynamic execution equipment to achieve precise positioning and synchronized actions.

Experimental and testing equipment: used for data acquisition, testing, and performance analysis of high-speed rotating machinery.
