GIDINGS&LEWIS  502-02425-01解码发电机模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

Giddings & Lewis 502-02425-01 是 PiC 系列控制系统中的解码发电机模块，用于将旋转机械的位置或速度信息转换为数字信号供控制系统使用。它接收编码器或旋转传感器的信号，通过内部解码电路处理后，将精确的位置信息或速度数据输出给控制器，实现高精度运动控制。

产品特点

1. 高精度信号解码

• 支持增量编码器和绝对编码器信号输入。

• 将旋转机械运动转化为数字量信号，保证位置和速度数据精确可靠。

2. 多通道处理能力

• 可同时处理多路编码器信号，实现多轴系统的数据采集。

• 适应复杂多轴运动控制需求。

3. 电气隔离与保护

• 输入与输出之间具备光电隔离，提高抗干扰能力。

• 内置过流、短路保护，防止模块或控制器损坏。

4. 工业适应性

• 抗振动、抗冲击设计，适合机床和工业自动化环境。

• EMC 抗干扰能力强，保证信号稳定传输。

5. 状态指示与维护便利

• LED 指示灯显示模块工作状态及信号处理情况。

• 模块化设计，方便安装、调试及现场更换。

应用领域

• 数控机床：采集主轴或进给轴的旋转位置与速度信息，实现闭环控制。

• 多轴自动化系统：处理多个编码器信号，实现多轴联动和插补控制。

• 工业自动化生产线：采集传感器或旋转设备数据，确保生产线动作精准。

• 精密加工和测试设备：提供高分辨率位置与速度数据，支持精密操作和测量。

• 设备监控与数据采集：实时采集旋转机械状态，为系统诊断和优化提供数据支持。

英文资料：

Product Overview

Giddings&Lewis 502-02425-01 is a decoding generator module in the PiC series control system, used to convert the position or speed information of rotating machinery into digital signals for use by the control system. It receives signals from encoders or rotation sensors, processes them through internal decoding circuits, and outputs accurate position or velocity data to the controller to achieve high-precision motion control.

Product Features

High precision signal decoding

Supports incremental encoder and absolute encoder signal input.

Convert the motion of rotating machinery into digital signals to ensure accurate and reliable position and velocity data.

Multi channel processing capability

It can simultaneously process multiple encoder signals to achieve data acquisition in multi axis systems.

Adapt to complex multi axis motion control requirements.

Electrical isolation and protection

There is photoelectric isolation between input and output to improve anti-interference ability.

Built in overcurrent and short-circuit protection to prevent module or controller damage.

Industrial adaptability

Anti vibration and anti impact design, suitable for machine tools and industrial automation environments.

EMC has strong anti-interference ability, ensuring stable signal transmission.

Status indication and convenient maintenance

The LED indicator light displays the working status and signal processing of the module.

Modular design, convenient for installation, debugging, and on-site replacement.

Application field

Numerical Control Machine Tool: Collecting the rotational position and speed information of the spindle or feed axis to achieve closed-loop control.

Multi axis automation system: processes multiple encoder signals to achieve multi axis linkage and interpolation control.

Industrial automation production line: Collect sensor or rotating equipment data to ensure precise production line actions.

Precision machining and testing equipment: providing high-resolution position and velocity data, supporting precision operations and measurements.

Equipment monitoring and data collection: Real time collection of rotating machinery status to provide data support for system diagnosis and optimization.

2.产      品      展      示
