GIDINGS&LEWIS 502-03898-50直流输出板 PDF资料
1.产 品 资 料 介 绍：
产品概述
Giddings & Lewis 502-03898-50 是 PiC 系列控制系统中的直流输出板，用于将控制器的逻辑信号转换为可驱动直流负载的电气信号。该模块在数控机床和自动化设备中，用于控制继电器、电磁阀、指示灯或其他直流执行元件，实现控制系统与机械动作的接口。
产品特点
多通道直流输出
提供多个独立输出通道，可同时控制多路直流负载。
各通道之间电气隔离，降低干扰和故障传播风险。
高可靠性与保护功能
内置过流、短路保护，防止模块及负载损坏。
工业级设计，抗振动、抗冲击，适应复杂工作环境。
状态指示与维护便利
LED 指示灯显示各输出通道工作状态，便于现场监控和故障排查。
模块化结构，方便安装、替换和系统扩展。
工业环境适应性
EMC 抗干扰能力强，可在电磁噪声较强的工业环境下稳定运行。
适应宽温度和湿度范围，满足工业控制要求。
系统兼容性
与 PiC 系列控制器及其他模块无缝连接。
支持中大型控制系统中直流负载的控制需求。
应用领域
数控机床：驱动夹具、电磁阀、润滑泵及其他直流执行装置。
自动化生产线：控制输送机械、分拣设备和装配机械的动作。
过程控制系统：驱动直流阀门、泵及报警设备。
信号指示与报警系统：驱动指示灯和蜂鸣器，实现状态显示与报警。
英文资料：
Product Overview
Giddings&Lewis 502-03898-50 is a DC output board in the PiC series control system, used to convert the logic signals of the controller into electrical signals that can drive DC loads. This module is used in CNC machine tools and automation equipment to control relays, solenoid valves, indicator lights, or other DC actuators, achieving the interface between the control system and mechanical actions.
Product Features
Multi channel DC output
Provide multiple independent output channels to simultaneously control multiple DC loads.
Electrical isolation between channels reduces the risk of interference and fault propagation.
High reliability and protection function
Built in overcurrent and short-circuit protection to prevent module and load damage.
Industrial grade design, resistant to vibration and impact, suitable for complex working environments.
Status indication and convenient maintenance
LED indicator lights display the working status of each output channel, facilitating on-site monitoring and troubleshooting.
Modular structure, convenient for installation, replacement, and system expansion.
Industrial environment adaptability
EMC has strong anti-interference ability and can operate stably in industrial environments with strong electromagnetic noise.
Adapt to a wide temperature and humidity range to meet industrial control requirements.
system compatibility
Seamless connection with PiC series controllers and other modules.
Support the control requirements of DC loads in medium and large-scale control systems.
Application field
CNC machine tools: drive fixtures, solenoid valves, lubrication pumps, and other DC actuators.
Automated production line: controls the actions of conveying machinery, sorting equipment, and assembly machinery.
Process control system: drives DC valves, pumps, and alarm devices.
Signal indication and alarm system: Drive indicator lights and buzzers to achieve status display and alarm.
2.产 品 展 示
