GIDINGS&LEWIS  502-03420-00 伺服接口模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

Giddings & Lewis 502-03420-00 伺服接口模块是 PiC 系列控制系统中的关键模块，用于连接伺服驱动器和控制系统。它负责将控制器发出的运动指令转换为伺服驱动器可识别的控制信号，同时接收伺服电机的反馈信号，实现闭环控制。该模块是实现高精度、多轴运动控制的核心部件之一。

产品特点

1. 多轴支持

• 可同时连接多台伺服驱动器，实现多轴同步控制。

• 支持多种伺服电机类型和反馈装置，如增量编码器、绝对编码器。

2. 闭环控制能力

• 接收伺服驱动器反馈信号，实现位置、速度和力矩闭环控制。

• 提供高精度运动控制和快速响应能力。

3. 高速信号处理

• 支持高速数据采集和控制信号输出，满足快速运动和高性能加工需求。

• 内部逻辑优化，确保伺服指令精确传递。

4. 信号隔离与保护

• 通道间光电隔离，增强系统安全性与抗干扰性。

• 内置短路、过流保护功能，防止驱动器或模块损坏。

5. 状态监控与维护便利

• LED 状态指示灯显示模块运行状态及通道信号情况。

• 模块化设计，便于现场安装、调试和更换。

6. 工业环境适应性

• 抗振动、抗冲击设计，适合机床和自动化生产环境。

• EMC 抗干扰能力强，保证模块在复杂工业环境下稳定运行。

应用领域

• 数控机床：驱动主轴或进给轴伺服系统，实现高精度加工。

• 多轴运动控制系统：支持多轴联动与插补控制。

• 自动化生产线：控制机器人和搬运机械，实现精确定位与动作控制。

• 精密加工设备：满足高重复精度和快速响应的控制要求。

英文资料：

Product Overview

The Giddings&Lewis 502-03420-00 servo interface module is a key module in the PiC series control system, used to connect servo drives and control systems. It is responsible for converting the motion commands issued by the controller into recognizable control signals for the servo drive, while receiving feedback signals from the servo motor to achieve closed-loop control. This module is one of the core components for achieving high-precision, multi axis motion control.

Product Features

Multi axis support

Multiple servo drives can be connected simultaneously to achieve multi axis synchronous control.

Supports multiple types of servo motors and feedback devices, such as incremental encoders and absolute encoders.

Closed loop control capability

Receive feedback signals from servo drives to achieve closed-loop control of position, speed, and torque.

Provide high-precision motion control and fast response capability.

high speed signal processing

Support high-speed data acquisition and control signal output to meet the requirements of fast motion and high-performance machining.

Internal logic optimization ensures precise transmission of servo instructions.

Signal isolation and protection

Optoelectronic isolation between channels enhances system security and anti-interference capabilities.

Built in short-circuit and overcurrent protection functions to prevent damage to the driver or module.

Convenient status monitoring and maintenance

The LED status indicator light displays the operating status of the module and the status of channel signals.

Modular design facilitates on-site installation, debugging, and replacement.

Industrial environment adaptability

Anti vibration and anti impact design, suitable for machine tools and automated production environments.

EMC has strong anti-interference ability, ensuring stable operation of modules in complex industrial environments.

Application field

Numerical Control Machine Tool: Drive the spindle or feed axis servo system to achieve high-precision machining.

Multi axis motion control system: supports multi axis linkage and interpolation control.

Automated production line: Control robots and handling machinery to achieve precise positioning and motion control.

Precision machining equipment: meets the control requirements of high repeatability and fast response.

2.产      品      展      示
