GIDINGS&LEWIS  501-03122-00接口板 PDF资料

1.产 品 资 料 介 绍：

产品概述

Giddings & Lewis 501-03122-00 接口板是 PiC 系列控制系统中的关键模块，用于实现控制器与其他设备或模块之间的信号接口转换。它可以接收来自处理器或输入模块的信号，并将其转换为适合下级设备的电气信号，同时也能将外部设备的信号传送至控制系统，实现数据交换和控制指令传递。

产品特点

1. 多通道信号接口

• 提供多个独立输入/输出通道，支持同时处理多路信号。

• 可处理数字量、逻辑信号和特定脉冲信号。

2. 高可靠性设计

• 工业级元件制造，保证长期稳定运行。

• 抗振动、抗冲击设计，适应工业环境。

3. 信号隔离与保护

• 通道间具备电气隔离，降低干扰和故障传播风险。

• 内置过流和短路保护，提高系统安全性。

4. 状态指示与维护便利

• LED 指示灯显示信号状态和接口板工作情况。

• 模块化设计，便于现场安装、调试和更换。

5. 兼容性与扩展性

• 可与 PiC 系列控制器及输入/输出模块无缝连接。

• 支持系统扩展，可用于中大型自动化控制系统。

应用领域

• 数控机床：连接传感器、编码器及执行器，实现机床运动和加工过程控制。

• 自动化生产线：实现控制器与输送系统、分拣机械及装配设备的信号接口。

• 过程控制系统：处理传感器信号并控制阀门、泵及报警装置。

• 工业设备监控：提供数据采集和控制接口，实现设备状态监控与控制。

英文资料：

Product Overview

The Giddings&Lewis 501-03122-00 interface board is a key module in the PiC series control system, used to achieve signal interface conversion between the controller and other devices or modules. It can receive signals from processors or input modules, convert them into electrical signals suitable for downstream devices, and also transmit signals from external devices to the control system, achieving data exchange and control instruction transmission.

Product Features

Multi channel signal interface

Provide multiple independent input/output channels, supporting simultaneous processing of multiple signals.

Capable of processing digital quantities, logical signals, and specific pulse signals.

High reliability design

Manufacturing industrial grade components to ensure long-term stable operation.

Anti vibration and anti impact design, suitable for industrial environments.

Signal isolation and protection

There is electrical isolation between channels to reduce the risk of interference and fault propagation.

Built in overcurrent and short-circuit protection to enhance system safety.

Status indication and convenient maintenance

The LED indicator light displays the signal status and the working condition of the interface board.

Modular design facilitates on-site installation, debugging, and replacement.

Compatibility and Scalability

Can seamlessly connect with PiC series controllers and input/output modules.

Support system expansion and can be used for medium to large-scale automation control systems.

Application field

Numerical Control Machine Tool: Connect sensors, encoders, and actuators to achieve machine tool motion and machining process control.

Automated production line: Implement signal interfaces between controllers and conveyor systems, sorting machinery, and assembly equipment.

Process control system: processes sensor signals and controls valves, pumps, and alarm devices.

Industrial equipment monitoring: Provide data acquisition and control interfaces to achieve equipment status monitoring and control.

2.产      品      展      示
