GIDINGS&LEWIS M.1301.9608步进模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

Giddings & Lewis M.1301.9608 步进模块是其控制系统中的运动控制功能模块，专门用于控制步进电机。它能够将控制器的数字信号转换为脉冲和方向信号，以驱动步进电机，从而实现精确的位置和速度控制。

产品应用领域

1. 数控机床（CNC 设备）

• 适用于小型数控机床或辅助轴控制。

• 可实现进给驱动、辅助夹具调节、换刀机构等步进控制任务。

2. 自动化装配与搬运设备

• 用于控制直线模组、旋转平台，实现高精度定位。

• 广泛应用于自动化装配线、电子制造设备、PCB 插装机等。

3. 包装机械

• 驱动送料、切割、贴标、封装等执行机构。

• 适合需要高重复精度和定步距控制的包装动作。

4. 检测与测试设备

• 控制检测平台的移动，实现精确的位移扫描或工件定位。

• 常用于光学检测、电子元件检测、实验室自动化设备。

5. 印刷与纺织机械

• 在印刷机上用于纸张走料、套准控制。

• 在纺织机械上用于送纱、卷绕等需要稳定节拍的环节。

6. 医疗与科研仪器

• 控制自动进样器、显微定位台、实验设备等。

• 满足对小步距、高精度和稳定性的特殊需求。

应用优势

• 高精度：步进控制能实现精准的分度与位置控制。

• 可靠性强：结构简单、控制逻辑清晰，适合重复性高的应用。

• 成本适中：在中低速、高定位精度场合，比伺服系统更经济。

• 模块化集成：与 G&L 控制系统无缝结合，便于扩展多轴控制。

英文资料：

Product Overview

The Giddings&Lewis M.1301.9608 stepper module is a motion control function module in its control system, specifically designed to control stepper motors. It can convert the digital signal of the controller into pulse and direction signals to drive the stepper motor, thereby achieving precise position and speed control.

Product application areas

Numerical Control Machine Tool (CNC Equipment)

Suitable for small CNC machine tools or auxiliary axis control.

It can achieve step control tasks such as feed drive, auxiliary fixture adjustment, and tool changing mechanism.

Automated assembly and handling equipment

Used for controlling linear modules and rotating platforms to achieve high-precision positioning.

Widely used in automated assembly lines, electronic manufacturing equipment, PCB insertion machines, etc.

packaging machinery

Drive actuators for feeding, cutting, labeling, packaging, etc.

Suitable for packaging actions that require high repeatability and step distance control.

Testing and Inspection Equipment

Control the movement of the detection platform to achieve precise displacement scanning or workpiece positioning.

Commonly used in optical testing, electronic component testing, and laboratory automation equipment.

Printing and Textile Machinery

Used for paper feeding and register control on printing machines.

Used in textile machinery for yarn feeding, winding, and other processes that require a stable cycle time.

Medical and research instruments

Control automatic sampler, micro positioning table, experimental equipment, etc.

Meet the special requirements for small step size, high precision, and stability.

Application advantages

High precision: Step control can achieve precise division and position control.

Strong reliability: simple structure, clear control logic, suitable for applications with high repeatability.

Moderate cost: It is more economical than servo systems in situations with medium to low speed and high positioning accuracy.

Modular integration: seamlessly integrated with G&L control system, making it easy to expand multi axis control.
