GIDINGS&LEWIS 502-03061-02处理器模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

Giddings & Lewis 502-03061-02 处理器模块是 PiC900 控制系统的核心部件之一，相当于系统的中央处理单元（CPU）。它负责执行用户程序、协调输入输出模块的数据处理、实现运动控制逻辑和通信管理，是整个控制系统的“大脑”。

产品应用领域

1. 数控机床（CNC）

• 应用于车床、铣床、磨床、加工中心等设备。

• 提供多轴同步控制、位置运算与实时逻辑处理，保障加工精度和效率。

2. 自动化生产线

• 控制输送系统、分拣机械、装配线等。

• 与 I/O 模块、编码器模块、直流/交流输出板配合，实现动作顺序控制和实时监控。

3. 运动控制系统

• 驱动伺服电机、步进电机，实现多轴联动控制。

• 支持插补、速度曲线规划、加减速控制等高性能运动功能。

4. 过程控制行业

• 在冶金、石化、电力等行业中，用于逻辑运算、信号处理和数据采集。

• 可与模拟量模块协同，处理压力、温度、流量等过程变量。

5. 机器人与智能设备

• 用于机器人控制系统，负责路径规划与多关节协调。

• 在自动检测设备中执行实时信号采集与反馈控制。

6. 大规模工业控制系统

• 作为中央控制单元，与多块 I/O 模块和扩展板协作，适合中大型复杂控制场景。

• 通过通信接口与上位机、监控系统连接，形成完整的自动化解决方案。

应用优势

• 高性能：提供强大的指令处理与实时响应能力。

• 模块化：与 PiC900 系列 I/O 模块灵活组合，适应不同控制规模。

• 稳定性强：工业级设计，长期运行稳定可靠。

• 扩展性好：支持多任务处理、通信扩展与系统升级。

英文资料：

Product Overview

The Giddings&Lewis 502-03061-02 processor module is one of the core components of the PiC900 control system, serving as the central processing unit (CPU) of the system. It is responsible for executing user programs, coordinating data processing of input and output modules, implementing motion control logic and communication management, and is the "brain" of the entire control system.

Product application areas

Numerical Control Machine Tool (CNC)

Applied to equipment such as lathes, milling machines, grinders, machining centers, etc.

Provide multi axis synchronous control, position calculation, and real-time logic processing to ensure machining accuracy and efficiency.

Automatic production line

Control conveyor systems, sorting machinery, assembly lines, etc.

Cooperate with I/O modules, encoder modules, and DC/AC output boards to achieve action sequence control and real-time monitoring.

Motion control system

Drive servo motors and stepper motors to achieve multi axis linkage control.

Support high-performance motion functions such as interpolation, speed curve planning, acceleration and deceleration control.

Process control industry

Used for logical operations, signal processing, and data acquisition in industries such as metallurgy, petrochemicals, and power.

Can collaborate with analog modules to handle process variables such as pressure, temperature, and flow rate.

Robots and Intelligent Devices

Used for robot control systems, responsible for path planning and multi joint coordination.

Real time signal acquisition and feedback control are performed in automatic detection equipment.

Large scale industrial control system

As a central control unit, it collaborates with multiple I/O modules and expansion boards, making it suitable for medium to large complex control scenarios.

Connect with the upper computer and monitoring system through communication interfaces to form a complete automation solution.

Application advantages

High performance: Provides powerful instruction processing and real-time response capabilities.

Modularization: Flexible combination with PiC900 series I/O modules to adapt to different control scales.

Strong stability: Industrial grade design, stable and reliable long-term operation.

Good scalability: supports multitasking, communication expansion, and system upgrades.

2.产      品      展      示
