GIDINGS&LEWIS 502-03644-00直流输出板 PDF资料

1.产 品 资 料 介 绍：

产品概述

Giddings & Lewis 502-03644-00 直流输出板是 PiC900 系列控制系统中的功能模块，主要用于将控制器的逻辑信号转换为直流输出信号，以驱动外部负载。该模块能够为工业自动化设备中的电磁阀、继电器、灯光指示器及其他直流执行元件提供稳定的驱动能力。

技术参数

• 模块类型：直流数字输出板

• 输出点数：通常为多通道输出设计（常见为 16 点或 32 点）

• 输出电压：直流 24V 标准工业电压

• 输出电流能力：每通道具备一定负载驱动能力（典型为 0.5A 左右）

• 隔离保护：具备光电隔离，提升模块与外部电路之间的安全性和抗干扰性

• 诊断功能：设有 LED 状态指示灯，可显示各通道的输出状态，便于调试和维护

• 接口方式：采用标准背板连接与螺丝端子/插拔端子方式，方便接线

应用场景

1. 机床控制
   用于数控机床中的执行机构驱动，如控制润滑泵、电磁阀、夹紧装置等。

2. 自动化生产线
   可驱动输送带、分拣装置和包装系统中的直流执行单元，实现动作控制。

3. 过程控制系统
   在冶金、化工、能源等行业，用于输出直流控制信号，控制阀门开闭、继电器动作。

4. 信号指示与报警系统
   驱动警示灯、蜂鸣器等设备，实现状态显示与报警输出。

产品特点

• 稳定可靠：工业级设计，确保长时间连续运行。

• 隔离保护：通道之间与控制逻辑隔离，增强安全性与抗干扰性。

• 输出能力强：能够直接驱动中小功率直流负载。

• 维护便捷：LED 状态指示与模块化设计，便于安装、替换与现场调试。

• 兼容性好：可直接安装于 Giddings & Lewis PiC900 控制系统机架中，支持系统扩展。

英文资料：

Product Overview

The Giddings&Lewis 502-03644-00 DC output board is a functional module in the PiC900 series control system, mainly used to convert the logic signals of the controller into DC output signals to drive external loads. This module can provide stable driving capability for solenoid valves, relays, light indicators, and other DC actuators in industrial automation equipment.

Technical Specifications

Module type: DC digital output board

Output points: Typically designed for multi-channel output (commonly 16 or 32 points)

Output voltage: DC 24V standard industrial voltage

Output current capability: Each channel has a certain load driving capability (typically around 0.5A)

Isolation protection: equipped with photoelectric isolation to enhance the safety and anti-interference between the module and external circuits

Diagnostic function: equipped with LED status indicator lights, which can display the output status of each channel for easy debugging and maintenance

Interface method: Adopting standard backplane connection and screw terminal/plug-in terminal method for convenient wiring

Application scenarios

Machine tool control

Used for driving actuators in CNC machine tools, such as controlling lubrication pumps, solenoid valves, clamping devices, etc.

Automatic production line

It can drive the DC actuator units in conveyor belts, sorting devices, and packaging systems to achieve motion control.

process control system

In industries such as metallurgy, chemical engineering, and energy, it is used to output DC control signals, control valve opening and closing, and relay action.

Signal indication and alarm system

Drive warning lights, buzzers, and other devices to achieve status display and alarm output.

Product Features

Stable and reliable: Industrial grade design ensures long-term continuous operation.

Isolation protection: Isolation between channels and control logic enhances security and anti-interference.

Strong output capability: able to directly drive small and medium power DC loads.

Easy maintenance: LED status indication and modular design, convenient for installation, replacement, and on-site debugging.

Good compatibility: It can be directly installed in the Giddings&Lewis PiC900 control system rack and supports system expansion.

2.产      品      展      示
