GIDINGS&LEWIS 503-14035-00半波控制器 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 503-14035-00 半波控制器

产品概述

503-14035-00 是 Giddings & Lewis 控制系统中的 半波控制器模块，用于调节交流电设备的功率输出。该模块通过控制半波电流实现负载调节，可用于电机启动、加热设备或其他工业负载的功率控制，保证设备平稳运行并提升能效。

产品特点

1. 高精度功率控制

• 通过半波调制控制负载电流，实现精确功率输出。

• 适用于电机调速、加热控制及其他工业负载。

2. 快速响应

• 对输入信号和负载变化响应迅速，保证设备运行平稳。

3. 工业级可靠性

• 抗振动、耐高温、抗电磁干扰，适合严苛工业环境。

• 内置过载、过流及短路保护，提高设备安全性。

4. 模块化设计

• 可方便安装在控制柜或系统机架中，便于维护和更换。

• 支持与 G&L 控制系统 CPU、I/O 模块及其他控制单元集成。

5. 多功能应用

• 可用于调节电机启动电流、加热元件功率或其他半波控制负载。

• 支持连续控制和负载保护功能。

产品应用领域

• 数控机床：控制主轴或辅助设备的功率输出，实现平稳运行。

• 自动化生产线：调节电机和加热装置的功率，提高生产效率和设备寿命。

• 工业机器人系统：控制辅助执行机构或加热设备，实现精确动作。

• 包装与印刷机械：驱动加热元件或电机，实现工艺参数稳定控制。

• 实验与测试平台：调节功率输出，实现实验装置或负载的精确控制。

英文资料：

GIDINGS&LEWIS 503-14035-00 Half Wave Controller

Product Overview

503-14035-00 is a half wave controller module in the Giddings&Lewis control system, used to regulate the power output of AC equipment. This module achieves load regulation by controlling half wave current, which can be used for power control of motor starting, heating equipment or other industrial loads, ensuring smooth operation of equipment and improving energy efficiency.

Product Features

High precision power control

By using half wave modulation to control the load current, precise power output can be achieved.

Suitable for motor speed regulation, heating control, and other industrial loads.

quick response

Quickly respond to input signals and load changes to ensure smooth operation of the equipment.

Industrial grade reliability

Resistant to vibration, high temperature, and electromagnetic interference, suitable for harsh industrial environments.

Built in overload, overcurrent, and short-circuit protection to improve equipment safety.

modular design

Can be conveniently installed in control cabinets or system racks for easy maintenance and replacement.

Support integration with G&L control system CPU, I/O modules, and other control units.

multi-functional application

Can be used to adjust motor starting current, heating element power, or other half wave control loads.

Support continuous control and load protection functions.

Product application areas

Numerical Control Machine Tool: Control the power output of the spindle or auxiliary equipment to achieve smooth operation.

Automated production line: Adjust the power of motors and heating devices to improve production efficiency and equipment lifespan.

Industrial robot system: controls auxiliary actuators or heating equipment to achieve precise movements.

Packaging and printing machinery: Drive heating elements or motors to achieve stable control of process parameters.

Experimental and testing platform: Adjust power output to achieve precise control of experimental devices or loads.

2.产      品      展      示
