GIDINGS&LEWIS 50203674-22R2直流输出模块 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 502-03674-22R2 直流输出模块

产品概述

502-03674-22R2 是 Giddings & Lewis 系列控制系统中的 直流输出模块，主要用于向执行机构、继电器或其他直流负载提供稳定的控制信号。该模块设计用于工业环境，支持高可靠性输出和长期连续运行，广泛应用于数控机床及自动化设备。

产品应用领域

1. 数控机床控制系统

• 为电磁阀、直流马达和执行器提供可靠的直流控制信号。

• 用于辅助轴控制、冷却泵、润滑泵或刀库驱动的直流输出控制。

2. 自动化生产线

• 控制输送带、分拣机械及物料搬运设备的直流电机或执行机构。

• 可用于启动/停止信号、开关控制及状态反馈。

3. 工业机器人与机械手系统

• 为机器人末端执行器或夹具提供直流电源控制。

• 可实现精确动作控制及协同操作。

4. 包装与印刷机械

• 提供传动或辅助设备直流控制，如送料器、摆臂或夹紧机构。

• 支持高速启动/停止操作和连续运动控制。

5. 实验与测试平台

• 为测试装置中的执行机构、传感器或驱动电路提供直流输出。

• 支持多通道控制及实时状态监测。

产品优势

• 高可靠性：工业级设计，抗干扰、耐高温、耐振动，适合严苛环境。

• 稳定输出：为直流负载提供精确、可控的电压或电流输出。

• 模块化设计：便于集成至现有控制系统，支持快速更换。

• 多用途应用：可用于电机驱动、继电器控制、开关信号及其他直流负载控制。

• 安全保护：具备短路保护和过流防护功能，保障模块和负载安全运行。

英文资料：

GIDINGS&LEWIS 502-03674-22R2 DC output module

Product Overview

502-03674-22R2 is a DC output module in the Giddings&Lewis series control system, mainly used to provide stable control signals to actuators, relays, or other DC loads. This module is designed for industrial environments, supporting high reliability output and long-term continuous operation, and is widely used in CNC machine tools and automation equipment.

Product application areas

Numerical Control Machine Tool Control System

Provide reliable DC control signals for solenoid valves, DC motors, and actuators.

Used for DC output control of auxiliary shaft control, cooling pump, lubrication pump, or tool magazine drive.

Automatic production line

DC motors or actuators that control conveyor belts, sorting machinery, and material handling equipment.

Can be used for start/stop signals, switch control, and status feedback.

Industrial robots and robotic arm systems

Provide DC power control for robot end effectors or fixtures.

It can achieve precise motion control and collaborative operation.

Packaging and Printing Machinery

Provide DC control for transmission or auxiliary equipment, such as feeders, swing arms, or clamping mechanisms.

Supports high-speed start/stop operation and continuous motion control.

Experimental and testing platform

Provide DC output for the actuators, sensors, or drive circuits in the testing device.

Support multi-channel control and real-time status monitoring.

Product advantages

High reliability: Industrial grade design, anti-interference, high temperature resistance, vibration resistance, suitable for harsh environments.

Stable output: Provide precise and controllable voltage or current output for DC loads.

Modular design: easy to integrate into existing control systems and supports quick replacement.

Multi purpose applications: can be used for motor drive, relay control, switch signal, and other DC load control.

Safety protection: It has short-circuit protection and overcurrent protection functions to ensure the safe operation of modules and loads.

2.产      品      展      示
