GIDINGS&LEWIS DSA030-230-P 伺服驱动器

产品概述

Giddings & Lewis DSA030-230-P 属于 Centurion DSA 系列伺服驱动器，专为无刷交流伺服电机提供高性能数字化控制。它采用紧凑化设计，集成多种保护与通信功能，适合精密运动控制与工业自动化应用。

技术特点

1. 数字化控制：采用数字 PI/PID 算法，分别对应电流、速度与位置控制，响应快速且稳定。

2. 功率范围：支持连续输出功率等级 0.5 kW、1.0 kW、2.0 kW，覆盖中小型伺服系统需求。

3. 输入电源：230V 交流供电，适用于常见工业电源环境。

4. 反馈兼容性：可支持增量型编码器、正弦/余弦信号、绝对值编码器，适应不同电机配置。

5. 接口设计：

• 8 路光耦隔离数字输入

• 4 路光耦隔离数字输出

• 1 路继电器输出

• 1 路模拟输入（±10V/0-10V）

• 1 路模拟输出（可用于监控或扭矩共享）

• 串口通信接口（RS-232/422/485）

6. 安全保护：内置短路保护、过流保护、过温保护，确保系统运行稳定。

7. 结构设计：外形紧凑，重量约 2.1 kg，方便安装在空间受限的控制柜内。

应用场景

• 精密机床控制系统

• 机器人关节与多轴运动系统

• 包装与印刷机械

• 半导体加工设备

• 高速传输与分拣系统

产品优势

• 高响应速度：数字算法确保电机快速启停与动态控制。

• 精确控制：支持多种高分辨率编码器，提升定位精度。

• 可靠性强：过流、短路及过温保护机制延长系统寿命。

• 扩展性好：多种通信方式与接口设计便于与上位机或 PLC 集成。

• 适应性强：在 0–55℃ 工作环境及高湿、振动场合下仍能稳定运行。

英文资料：

GIDINGS&LEWIS DSA030-230-P servo drive

Product Overview

Giddings&Lewis DSA030-230-P belongs to the Centurion DSA series servo drive, designed to provide high-performance digital control for brushless AC servo motors. It adopts a compact design, integrates multiple protection and communication functions, and is suitable for precision motion control and industrial automation applications.

Technical Features

Digital control: using digital PI/PID algorithms, corresponding to current, speed, and position control, with fast and stable response.

Power range: Supports continuous output power levels of 0.5 kW, 1.0 kW, and 2.0 kW, covering the needs of small and medium-sized servo systems.

Input power supply: 230V AC power supply, suitable for common industrial power environments.

Feedback compatibility: Supports incremental encoders, sine/cosine signals, and absolute encoders to adapt to different motor configurations.

Interface design:

8-way optocoupler isolated digital input

4-channel optocoupler isolated digital output

1 relay output

1 analog input (± 10V/0-10V)

1 analog output (can be used for monitoring or torque sharing)

Serial communication interface (RS-232/422/485)

Safety protection: Built in short-circuit protection, overcurrent protection, and over temperature protection ensure stable system operation.

Structural design: Compact in appearance, weighing approximately 2.1 kg, convenient for installation in control cabinets with limited space.

Application scenarios

Precision machine tool control system

Robot joints and multi axis motion systems

Packaging and Printing Machinery

Semiconductor processing equipment

High speed transmission and sorting system

Product advantages

High response speed: Digital algorithms ensure fast start stop and dynamic control of the motor.

Precise control: Supports multiple high-resolution encoders to improve positioning accuracy.

Strong reliability: overcurrent, short circuit, and over temperature protection mechanisms extend the system's lifespan.

Good scalability: Multiple communication methods and interface designs facilitate integration with upper computers or PLCs.

Strong adaptability: able to operate stably in working environments ranging from 0-55 ℃ and high humidity and vibration situations.

2.产      品      展      示
