GIDINGS&LEWIS 502-03548-00输入模块 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 502-03548-00 输入模块

一、产品概述

502-03548-00 是 Giddings & Lewis 系列控制系统中的 工业输入模块，用于采集来自现场设备的数字和模拟信号，并将数据传输至控制器进行处理。该模块是数控机床、自动化生产线及工业机器人系统中关键的信号采集单元。

二、技术特点

1. 多通道输入

• 支持多路数字量输入，可连接传感器、开关、按钮等设备。

• 提供高精度模拟量输入，可采集电压、电流或其他工业标准信号。

2. 高速信号采集

• 输入通道响应快速，确保数字量和模拟量信号的实时采集。

• 满足高动态工业控制场景的需求。

3. 隔离与保护功能

• 输入通道与控制总线电气隔离，增强抗干扰能力。

• 内置过流、过压及短路保护，确保模块及系统安全。

4. 状态指示功能

• LED 指示灯显示各通道工作状态，便于现场调试和故障排查。

• 支持通道异常报警，快速定位问题。

5. 模块化安装

• 可安装于 G&L 控制机架或标准插槽，方便系统扩展和维护。

• 与 G&L 控制器及输出模块兼容，实现无缝集成。

6. 工业级耐用性

• 结构坚固，耐高温、抗振动、抗电磁干扰，适合长期连续运行。

英文资料：

GIDINGS&LEWIS 502-03548-00 Input Module

1、 Product Overview

502-03548-00 is an industrial input module in the Giddings&Lewis series control system, used to collect digital and analog signals from field devices and transmit the data to the controller for processing. This module is a key signal acquisition unit in CNC machine tools, automated production lines, and industrial robot systems.

2、 Technical features

Multi channel input

Supports multiple digital inputs and can be connected to devices such as sensors, switches, buttons, etc.

Provide high-precision analog input, capable of collecting voltage, current, or other industrial standard signals.

High speed signal acquisition

The input channel responds quickly, ensuring real-time acquisition of both digital and analog signals.

Meet the needs of high dynamic industrial control scenarios.

Isolation and protection function

The input channel is electrically isolated from the control bus to enhance anti-interference capability.

Built in overcurrent, overvoltage, and short-circuit protection ensures the safety of modules and systems.

Status indication function

LED indicator lights display the working status of each channel, facilitating on-site debugging and troubleshooting.

Support channel abnormal alarm and quickly locate problems.

modular installation

Can be installed on G&L control racks or standard slots for easy system expansion and maintenance.

Compatible with G&L controllers and output modules, achieving seamless integration.

Industrial grade durability

The structure is sturdy, resistant to high temperatures, vibrations, and electromagnetic interference, suitable for long-term continuous operation.
