GIDINGS&LEWIS  DSA-175-230S伺服驱动器 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS DSA-175-230S 伺服驱动器

一、产品概述

DSA-175-230S 是 Giddings & Lewis 系列中功率型 交流伺服驱动器，用于高性能伺服电机的精确控制。它可提供闭环速度、位置和转矩控制，广泛应用于数控机床、自动化生产线及机器人系统中，实现高速、高精度运动控制。

二、技术特点

• 额定输入：230VAC 三相电源，符合工业电压标准。

• 输出功率：适用于中功率至高功率伺服电机，连续和瞬时过载能力兼顾。

• 控制模式：支持位置环、速度环和转矩环闭环控制模式，满足不同应用需求。

• 反馈接口：兼容高分辨率编码器或霍尔传感器，实现精确闭环控制。

• 保护功能：内置过流、过压、欠压、短路及过温保护，提高系统安全性。

• 模块化设计：便于与控制器、I/O 模块及伺服电机集成，便于系统扩展。

三、应用领域

1. 数控机床

• 驱动机床主轴和进给轴，实现高速高精度加工。

• 控制夹具、液压系统及辅助设备动作。

2. 自动化生产线

• 控制搬运、装配、检测等执行机构，实现流程自动化。

• 支持快速启停与频繁换向动作。

3. 机器人系统

• 驱动机器人关节，实现闭环位置和速度控制。

• 适用于搬运、焊接、喷涂、分拣等精密任务。

4. 包装与印刷机械

• 控制送料、分切、张力及同步动作，实现高质量生产。

5. 物流与物料搬运

• 控制输送机、堆垛机、自动仓储设备，实现精确定位与同步搬运。

英文资料：

GIDINGS&LEWIS DSA-175-230S servo drive

1、 Product Overview

DSA-175-230S is a high-power AC servo drive in the Giddings&Lewis series, used for precise control of high-performance servo motors. It can provide closed-loop speed, position, and torque control, widely used in CNC machine tools, automated production lines, and robot systems to achieve high-speed and high-precision motion control.

2、 Technical features

Rated input: 230VAC three-phase power supply, in compliance with industrial voltage standards.

Output power: Suitable for medium to high power servo motors, with both continuous and instantaneous overload capabilities.

Control mode: Supports closed-loop control modes of position loop, speed loop, and torque loop to meet different application requirements.

Feedback interface: compatible with high-resolution encoders or Hall sensors, achieving precise closed-loop control.

Protection function: Built in overcurrent, overvoltage, undervoltage, short circuit, and over temperature protection to improve system safety.

Modular design: easy to integrate with controllers, I/O modules, and servo motors, facilitating system expansion.

3、 Application Fields

CNC machine tool

Drive the spindle and feed axis of the machine tool to achieve high-speed and high-precision machining.

Control the actions of fixtures, hydraulic systems, and auxiliary equipment.

Automatic production line

Control the execution mechanisms of handling, assembly, and inspection to achieve process automation.

Support quick start stop and frequent reversing actions.

robot system

Drive robot joints to achieve closed-loop position and velocity control.

Suitable for precision tasks such as handling, welding, spraying, sorting, etc.

Packaging and Printing Machinery

Control feeding, slitting, tension, and synchronous actions to achieve high-quality production.

Logistics and Material Handling

Control conveyors, stackers, and automatic storage equipment to achieve precise positioning and synchronized handling.

2.产      品      展      示
